Description
SPECIFICATIONS:
PERFORMANCE | |
Processor |
Intel® Core™ Ultra 7 258V, 8C (4P + 4LPE) / 8T, Max Turbo up to 4.8GHz, 12MB |
AI PC Category |
Copilot+ PC |
NPU |
Integrated Intel® AI Boost, up to 47 TOPS |
Graphics |
Integrated Intel® Arc™ Graphics 140V |
Chipset |
Intel® SoC Platform |
Memory |
32GB Soldered LPDDR5x-8533, MoP Memory |
Memory Slots |
Memory soldered to systemboard, no slots, dual-channel |
Max Memory |
32GB soldered memory, not upgradable |
Storage |
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe® Opal 2.0 |
Storage Support |
One drive, up to 2TB M.2 2242 SSD |
Storage Slot |
One M.2 2242 PCIe® 4.0 x4 slot |
Card Reader |
None |
Audio Chip |
High Definition (HD) Audio, Cirrus Logic® CS42L43 |
Speakers |
Stereo speakers, 2W x2, Dolby Atmos® |
Camera |
UHD 8.0MP with Large Sensor + IR Discrete, with E-Shutter, ToF Sensor, MIPI |
Microphone |
2x, Array |
Battery |
Integrated 55Wh |
Power Adapter |
65W USB-C® Slim GaN (3-pin) |
DESIGN | |
Display |
14" 2.8K (2880x1800) OLED 500nits Anti-reflection / Anti-smudge, 100% DCI-P3, 30-120Hz VRR, DisplayHDR™ True Black 600, Dolby Vision®, Touch |
Touchscreen |
OGM, 10-point Multi-touch |
Keyboard |
Backlit, English |
Touchpad |
Buttonless glass surface multi-touch Haptic Touchpad, supports Precision TouchPad (PTP), 80 x 130 mm (3.15 x 5.12 inches) |
Case Color |
Grey |
Case Material |
Aluminium (Top), Aluminium (Bottom) |
Pen |
Pen Upgradable (Purchase Separately) |
Dimensions (WxDxH) |
311.8 x 212.3 x 6.7 - 17.18 mm (12.28 x 8.36 x 0.26 - 0.68 inches) |
Weight |
Starting at 1.27 kg (2.80 lbs) |
SOFTWARE | |
Operating System |
Windows® 11 Pro, English (US) / English (UK) |
Bundled Software |
Intel® Connectivity Performance Suite + Lenovo® AI Now |
CONNECTIVITY | |
Ethernet |
No Onboard Ethernet |
WLAN + Bluetooth |
Intel® Wi-Fi® 7 BE201, 802.11be 2x2 + BT5.4 |
WWAN |
Non-WWAN |
SIM Card |
None |
NFC |
None |
Standard Ports |
2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1 1x HDMI® 2.1, up to 4K/60Hz 1x Headphone / microphone combo jack (3.5mm) |
Optional Ports (configured) |
None |
Docking |
Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad® X9-14 Gen 1 |
SECURITY & PRIVACY | |
Smart Card Reader |
None |
Security Chip |
Discrete TPM 2.0 Enabled |
Fingerprint Reader |
Touch Style, Match-on-Chip, Integrated in Power Button |
Other Security |
ToF Human Presence Detection (2.8K models) E-shutter IR camera for Windows® Hello (facial recognition) |
MANAGEABILITY | |
System Management |
Non-vPro® |
ACCESSORIES | |
Bundled Accessories |
None |
CERTIFICATIONS | |
Green Certifications |
ENERGY STAR® 8.0 EPEAT™ Gold Registered ErP Lot 6/26 RoHS compliant TCO Certified 10.0 |
Other Certifications |
Eyesafe® Certified 2.0 Intel® Evo™ Platform |
Mil-Spec Test |
MIL-STD-810H military test passed |
