Description
SPECIFICATIONS:
DISPLAY |
|
Size [Inch] |
23.8 |
Aspect Ratio |
16:9 |
Panel Type |
IPS |
Surface Treatment |
Anti-Glare |
Response Time |
5ms (GtG at Faster) |
Resolution |
1920 x 1080 |
Pixel Pitch [mm] |
0.2745 x 0.2745 |
Colour Depth (Number of Colours) |
16.7M |
Viewing Angle (CR≥10) |
178º(R/L), 178º(U/D) |
Brightness (Typ.) [cd/m²] |
250 |
Contrast Ratio (Typ.) |
1300:1 |
Colour Gamut (Typ.) |
sRGB 99% (CIE1931) |
Colour Gamut (Min.) |
sRGB 90% |
Refresh Rate (Max.) [Hz] |
100 |
Brightness (Min.) [cd/m²] |
200 |
Contrast Ratio (Min.) |
910:1 |
Colour Bit |
8bit (6bit+FRC) |
Size [cm] |
60.4 |
CONNECTIVITY |
|
Built-in KVM |
YES |
HDMI |
YES(1ea) |
Daisy Chain |
YES(FHD/60Hz) |
DisplayPort |
YES(In 1ea / Out 1ea) |
DP Version |
1.4 |
USB-C |
YES(1ea) |
Headphone out |
3-pole (Sound Only) |
LAN (RJ-45) |
YES |
USB Downstream Port |
4x USB3.2 Gen1 |
USB Upstream Port |
1x USB3.2 Gen1 |
USB-C (Data Transsmission) |
YES |
USB-C (Max. Resolution at Hz) |
1920X1080 @100Hz |
USB-C (Power Delivery) |
65W |
FEATURES |
|
Colour Weakness |
YES |
Smart Energy Saving |
YES |
Flicker Safe |
YES |
Dynamic Action Sync |
YES |
Black Stabiliser |
YES |
Reader Mode |
YES |
Super Resolution+ |
YES |
Auto Input Switch |
YES |
MECHANICAL |
|
Display PositionAdjustments |
Tilt/Height/Swivel/Pivot |
Borderless Design |
3-Side Virtually Borderless Design |
Wall Mountable [mm] |
100 x 100 |
OneClick Stand |
YES |
SOUND |
|
Speaker |
2W x 2 |
DIMENSIONS/WEIGHTS |
|
Dimension in Shipping (W x H x D) [mm] |
613*184*491 |
Dimension with Stand (W x H x D) [mm] |
539.6*517.5*250(Up Height) |
Dimension without Stand (W x H x D) [mm] |
539.6*323*50 |
Weight in Shipping [kg] |
8.3kg |
Weight with Stand [kg] |
6.6kg |
Weight without Stand [kg] |
3.8kg |
POWER |
|
Power Consumption (Sleep Mode) |
Less than 0.5W |
Power Consumption (DC Off) |
Less than 0.3W |
AC Input |
100~240V (50/60Hz) |
Type |
Built-in Power |
DC Output |
20.5V/6.5A |
ACCESSORY |
|
Display Port |
YES |
Others (Accessory) |
Screw, Cable Holder |
Power Cord |
YES |
USB-C |
YES |
SW APPLICATION |
|
Dual Controller |
YES |
STANDARD |
|
UL (cUL) |
YES |
CE |
YES |
