Description
SPECIFICAITONS:
DISPLAY |
|
Size (Inch) |
23.8 |
Size (cm) |
60.4 cm |
Resolution |
1920 x 1080 |
Panel Type |
IPS |
Aspect Ratio |
16:9 |
Pixel Pitch |
0.2745 x 0.2746 mm |
Brightness (Min.) |
200 cd/m² |
Brightness (Typ.) |
250 cd/m² |
Colour Gamut (Typ.) |
NTSC 72% (CIE1931) |
Colour Depth (Number of Colours) |
16.7M |
Colour Bit |
8bit (6bit+FRC) |
Contrast Ratio (Min.) |
600:1 |
Contrast Ratio (Typ.) |
1000:1 |
Response Time |
5ms (GtG at Faster) |
Refresh Rate (Max.) [Hz] |
75 |
Viewing Angle (CR≥10) |
178º(R/L), 178º(U/D) |
Surface Treatment |
Anti-Glare |
Curvature |
NO |
FEATURES |
|
HDR 10 |
NO |
Dolby Vision™ |
NO |
VESA DisplayHDR™ |
NO |
HDR Effect |
NO |
Mini-LED Technology |
NO |
Nano IPS™ Technology |
NO |
Advanced True Wide Pol. |
NO |
Colour Calibrated in Factory |
NO |
HW Calibration |
NO |
Auto Brightness |
NO |
Flicker safe |
YES |
Picture Mode |
Custom, Reader, Photo, Colour Weakness, Cinema, Game |
Reader Mode |
YES |
Colour Weakness |
YES |
Super Resolution+ |
YES |
Motion Blur Reduction Tech. |
NO |
NVIDIA G-Sync™ |
NO |
AMD FreeSync™ |
FreeSync |
VRR |
NO |
Black Stabiliser |
Black Stabiliser |
Dynamic Action Sync |
YES |
Crosshair |
YES |
FPS Counter |
NO |
OverClocking |
NO |
User Defined Key |
NO |
Auto Input Switch |
NO |
RGB LED Lighting |
NO |
PBP |
NO |
PIP |
NO |
Smart Energy Saving |
YES |
OSD Language |
18 countries (English, Germanic, French, Spanish, Italian, Swedish, Finnish, Portuguese, Portuguese(brazil), Polish, Russian, Greek, Ukrainian, Chinese, Traditional Chinese, Japanese, Korean, Hindi) |
Camera |
NO |
Mic |
NO |
SW APPLICATION |
|
LG Calibration Studio (True Colour Pro) |
NO |
Dual Controller |
NO |
OnScreen Control (LG Screen Manager) |
YES |
LG UltraGear™ Control Center |
NO |
LG UltraGear™ Studio |
NO |
CONNECTIVITY |
|
D-Sub |
YES(1ea) |
D-Sub (V Frequency) |
56~75Hz |
D-Sub (Max. Resolution at Hz) |
1920 x 1080 at 60Hz |
DVI-D |
NO |
HDMI |
YES(1ea) |
HDMI Version |
1.4 |
HDMI (HDCP Version) |
1.4 |
HDMI (w/o VRR) |
56~75Hz |
HDMI (w/ VRR) |
48~75Hz |
DisplayPort |
NO |
Thunderbolt |
No |
Thunderbolt (Data Transsmission) |
No |
USB-C |
NO |
USB-C (Data Transsmission) |
NO |
Daisy Chain |
NO |
USB Upstream Port |
NO |
USB Downstream Port |
NO |
Built-in KVM |
NO |
LAN (RJ-45) |
NO |
SPDIF out (Optical Digital Audio Out) |
NO |
Audio In |
No |
Mic In |
No |
Headphone Out |
NO |
Line out |
No |
[Location] |
Back(Horizontal) |
SOUND |
|
Speaker |
NO |
Bluetooth Connectivity |
NO |
DTS HP:X |
NO |
Maxx Audio |
NO |
Rich Bass |
NO |
POWER |
|
Type |
External Power(Adapter) |
AC Input |
100~240V (50/60Hz) |
DC Output |
24W (19V / 1.3A) |
Power Consumption (Typ.) |
19.0W |
Power Consumption (Max.) |
22.0W |
Power Consumption (Sleep Mode) |
Less than 0.3W |
Power Consumption (DC Off) |
Less than 0.3W |
MECHANICAL |
|
Borderless Design |
3-Side Virtually Borderless Design |
Colour |
Matt Black |
Display Position Adjustments |
Tilt |
Tilt |
-5~20ºWall Mountable 75 x 75 mm |
Base Detachable |
YES |
OneClick Stand |
NO |
DIMENSIONS/WEIGHT |
|
Dimension with Stand (W x H x D) |
539.9 x 415.9 x 181.9mm |
Dimension without Stand (W x H x D) |
539.9 x 321.4 x 56.2mm |
Dimension in Shipping (W x H x D) |
625 x 141 x 418mm |
Weight with Stand |
2.6kg |
Weight without Stand |
2.3kg |
Weight in Shipping |
3.9kg |
Pallet Stuffing (20ft/40ft/40ft HC) |
675/1500/1700 |
STANDARD |
|
TCO |
NO |
EPA |
NO |
TUV-TYPE |
YES |
TUV-GS |
NO |
TUV-Ergo |
NO |
CB |
YES |
UL (cUL) |
YES |
FCC-B |
YES |
EPEAT (USA) |
NO |
EPEAT (Germany) |
NO |
ErP |
YES |
CE |
YES |
BIS (for India) |
NO |
VCCI (for Japan) |
NO |
BSMI (for Taiwan) |
YES |
KC (for Rep. of Korea) |
YES |
CCC (for China) |
NO |
Thunderbolt |
NO |
USB-C (USB-IF) |
NO |
USB-C (VESA) |
NO |
VESA wall mount standard |
NO |
Others (Standard) |
CEC,EAC,SIRC,MEPS |
ACCESSORIES |
|
Adapter |
YES |
Adapter (Colour) |
Black |
Power Cord |
Depends on Country |
Power Cord (Colour/Length) |
Black / 1.5m |
D-Sub |
NO |
D-Sub (Colour/Length) |
NO |
DVI-D |
NO |
DVI-D (Colour/Length) |
NO |
HDMI |
YES |
HDMI (Colour/Length) |
Black / 1.5m |
Display Port |
NO |
Display Port (Colour/Length) |
NO |
Thunderbolt |
NO |
Thunderbolt (Colour/Length) |
NO |
USB Type C |
NO |
USB Type C (Colour/Length) |
No |
USB A to B |
NO |
USB A to B (Colour/Length) |
NO |
Remote Controller |
NO |
Remote Controller (Colour) |
NO |
Calibration Report (Paper) |
NO |
Others (Accessory) |
User Screw (2EA) |
