Lian Li SP750 750W 80+ Gold Fully Modular SFX Power Supply - Black

Power Supply Design

Full modular

Colour

Black

Material

Steel / brush aluminium housing

Form Factor

SFX

Certification

80 PLUS Gold

Max. DC Output

750W

Combined +3.3V & +5V

100W

Combined +12V

744W

Input Voltage

90 ~ 264 Vrms

Input Frequency Range

47Hz – 63 Hz

PFC

Active PFC (PF)>0.90 at full load

Efficiency

91.94 ~ 89.09 at 20% ~ 100% Load

Connectors

1 x 24 / 20-Pin motherboard connector (300mm) x 1pcs
  2 x 8 / 4-Pin EPS / ATX 12V connector (400mm) x 2pcs
  1 x 8 / 6-Pin PCIe connector (450mm-100mm_6-Pin PCIe
  Connector) x 1pcs
  1 x 8 / 6-Pin PCIe connector (450mm) x 1pcs
  8 x SATA connector (100mm-115mm-115mm-115mm) x 2pcs
  2 x 4-Pin Peripheral connector (100mm-115mm) x 1pcs

Noise Level

17.6 – 31.8 dBA

AC Input

100-240V 10-5_A 60-50_Hz

DC Output

+3.3V, +5V, +12V, -12V, +5Vsb

Max Output Current

15, 15, 62, 0.3, 2.5

Max Combined Power

100W, 744W, 3.6W, 12.5W

Total Power

750W
