Description
SPECIFICATIONS:
Dimensions |
Height: 159 mm Width: 12 mm Depth: 8 mm Weight: 20 g |
Technical Specifications |
Protection: 4 ft (1.2 m) drop
Power and Connectivity Lithium battery Up to 7 hours of active writing time To turn on, slide the button down towards tip After 5 seconds, lights turn off When idle, the LED lights will turn on briefly to show battery life when it detects movement, transitioning from idle to active writing mode Battery life indicator Battery > 66%, 3 green LED Battery > 33%, 2 green LED Battery >15%, 1 green LED Battery <15%, 1 red blinking LED
Charge via iPad USB-C cable After 5 minutes of inactivity, Crayon will switch to idle mode To turn off, slide button up towards charging port To charge Charge to 33%, 3 LED blink continuously Charge to 66%, 1 LED is solid green, 2 LED blink continuously Charge to 99%, 2 LED are solid green, 1 LED blink Charge to 100%, 3 solid green LED |
Tip |
Replaceable (purchased separately) Tilt sensitivity for dynamic line weight Palm rejection technology ignores stray touches |
Materials |
Tube: Aluminum Tip cover: PC+ABS |
Compatible devices |
iPad Pro 12.9-inch iPad Pro 12.9-inch (6th gen) Model: A2436, A2764, A2437, A2766 iPad Pro 12.9-inch (5th Gen) Model: A2378, A2461, A2379, A2462 iPad Pro 12.9-inch (4th gen) Model: A2229, A2069, A2232, A2233 iPad Pro 12.9-inch (3rd Gen) Model: A1876, A2014, A1895, A1983
iPad Pro 11-inch iPad Pro 11-inch (4th gen) Model: A2759, A2435, A2761, A2762 iPad Pro 11-inch (3rd Gen) Model: A2377, A2459, A2301, A2460 iPad Pro 11-inch (2nd Gen) Model: A2228, A2068, A2230, A2231 iPad Pro 11-inch (1st Gen) Model: A1980, A2013, A1934, A1979
iPad iPad (10th gen) Model: A2696, A2757, A2777 iPad (9th gen) Model: A2602, A2603, A2604, A2605 iPad (8th Gen) Model: A2270, A2428, A2429, A2430 iPad (7th gen) Model: A2197, A2200, A2198 iPad (6th Gen) Model: A1893, A1954
iPad Air iPad Air (5th gen) Model: A2588, A2589, A2591 iPad Air (4th gen) Model: A2316, A2324, A2325, A2072 iPad Air (3rd Gen) Model: A2152, A2123, A2153, A2154
iPad Mini iPad mini (6th gen) Model: A2567, A2568, A2569 iPad mini® (5th gen) Model: A2133, A2124, A2126, A2125
*All iPad models must be updated to iOS 12.2 and above |
In the Box |
Logitech Crayon Quick Start Guide |
