Description
SPECIFICATIONS:
Dimensions |
Height: 73.3 mm Width: 469.2 mm Depth: 73 mm Weight: 1.8 kg |
General Specifications |
Enclosure: All-in-one enclosure Device Management: Logitech Sync Displays Supported: BYOD mode: 1; Dedicated computer mode: computer/application dependent Display Resolution: 1080p Network Protocol Support: IPv4, IPv6 Proxy Support: IP based Proxy, FQDN based Proxy, Proxy using PAC file |
Camera |
Digital pan: ±48° at 4x zoom Digital Tilt: ±32° at 4x zoom Zoom: 4X HD digital zoom Diagonal Field of View: 120° Horizontal Field of View: 113° Vertical Field of View: 80° Resolution: 4K |
Speakers |
Driver: 55 mm with bass reflex enclosure and patented suspension design Sensitivity: 83 dB SPL @1W +/-2dB @ 1 meter Rated Power: 8W THD at 1W, 1kHz : <2% Speaker Sampling Rate: 48KHz Impedance: 4 Ohms |
Microphones |
Frequency Response: 90Hz – 16kHz Sensitivity: -36dBFS +/-1 dB @ 1Pa Microphone data rate output: 48 kHz Pickup Range: Up to 7m Beamforming Elements: Six omnidirectional digital MEMS microphones forming five adaptive acoustic broadside beams Audio processing: AEC (Acoustic Echo Cancellation) VAD (Voice Activity Detector) Noise suppression: AI based de-noising algorithm |
Interfaces |
HDMI Out: 1 HDMI In: 1 USB: 1 x Type C USB 3.1 Network: 10/100/1G Ethernet WiFi: 802.11a/b/g/n/ac/ax Bluetooth: Bluetooth® Low Energy |
Power and Cables |
Power supply: Auto-sensing Operating Voltage/Power: 100-240V, 19V, 2.1A Power Supply Dimensions: 114 x 47 mm x 32.3 mm DC Cable: 3 m USB C to USB C 3.0 Cable: 3 m |
Environmental |
Operating temperature: 0 to 40°C Storage temperature: -25-70°C Humidity: 10 to 90% |
Security |
File Based Encryption: AES-128 Data Encryption: Symmetric Keys, PKI Device Identity: Protected by device attestation Device Access: Authenticated using API Key Protection: Arm TrustZone, RPMP Physical Security: Kensington security slot |
Compatibility |
Windows 10 and higher macOS: two most recent versions Network Connection: wired or wireless |
In the Box |
All-in-one MeetUp 2 with multi-function mount Power supply with region-specific plugs USB-C to USB-C 2.0 cable that is 3 m 2 wall anchors and 2 screws Quick start guide printed on the box |
