Description
SPECIFICATIONS:
Chipset |
INTEL B760 |
CPU |
Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors LGA 1700 |
Memory |
2x DDR5, Maximum Memory Capacity 96GB Memory Support DDR5 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz Supports Intel® XMP 3.0 OC Supports Dual-Controller Dual-Channel mode |
Onboard graphics |
1x VGA *Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz 1x HDMI™port *HDMI™ port supports up to 4K@30Hz *Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. |
Expansion slot |
1x PCIe 4.0 x16 slot 1x PCIe 3.0 x4 slot |
Storage |
M.2_1 slot (Key M), type 2242/2280 (supports PCIe 4.0 x4 mode) M.2_2 slot (Key M), type 2242/2280 (supports PCIe 4.0 x4 mode) 3 x SATA 6Gb/s ports |
RAID |
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
USB |
*Front USB (Total 6 ports) 2x USB 3.2 Gen1 Type A 4x USB 2.0 *Rear USB (Total 6 ports) 4x USB 3.2 Gen1 Type A 2x USB 2.0 |
LAN |
Realtek® RTL8111H 1G LAN |
Audio |
Realtek® ALC897 Codec 5.1-Channel High Definition Audio |
Internal I/O |
1x 24-pin Power Connector(ATX_PWR) 1x 8-pin Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2 x M.2 slots (Key-M) 3x SATA 6Gb/s ports 1x 2-Pin CLR_CMOS 1x 4-Pin BUZZER 1x Front Audio 1x COM_A Port 1x 2-Pin F_PANEL 1x TPM pin header(Support TPM 2.0) 1x 3-Pin SPDIF 1x 12V 4-Pin RGB |
LED feature |
4x Distributed Debug LED |
Operating system |
Support for Windows® 11 64-bit, Windows® 10 64-bit |
Form factor |
M-ATX 245mm x 190mm |
