Description
SPECIFICATIONS:
CPU |
Support for LGA1700 slots 12th、13th、14th-generation processor (CPU overclocking technology is not supported) TDP: 168W |
Chipset |
Intel®H610 High speed chipset |
Display |
2*HDMI ports, up to 4096x2160@30Hz resolution (HDMI1.4 and HDCP2.2) 1*DP1.2 port with up to 4096x2160@60Hz resolution |
Expansion interface |
1*PCIEX16 4.0 slot |
Audio |
Integrated ALC897 sound card chip |
Network |
LAN1 port Integrated Realtek8125BG Network Card Chip (10/100/1000/2500Mbit) LAN2 port Integrated Realtek8111H Network Card Chip (10/100/1000Mbit) |
Storage |
M2_SSD_A slot supports 2280 size PCIE X4 3.0 devices only (Front) M2_SSD_B slot supports 2280 size PCIE X2 3.0 devices only (Back) 4x SATA3.0 ports |
USB |
Onboard rear ports: 2 USB3.2 GEN1 ports, 3 USB2.0 ports On-board pins: 1 set (2) USB2.0 pins, 1 set (2) USB3.2 GEN1 pins |
In-board socket |
1x 24-PIN motherboard ATX power supply port 1x 8-PIN motherboard ATX 12V power port with 12V input 3x system fan pins and 1 CPU fan pin 1x CLR_CMOS pin |
Operating system |
Integrated ALC897 sound card chip |
