Description
SPECIFICATIONS:
Keyboard |
Wired Gasket Mount Design 75% Layout PCB: 1.6mm, with Ai03 DB 5° Typing angle 22.14 mm front height Dimension: 323.6 x 145.78 x 34.73 (mm) Default plate: Alu Case Material: 6063 Aluminum Case Finish: Anodized+Infill (No Sparkles, No Chamfer) Backplate and External Weight: Anodized+Infill Switches Type: Gateron KS37B, compatible with Gateron KS37, GATERON Magnetic FOX Switch, GATERON Dual-rail Magnetic Jade Mini E Switch The Orientation of the Switches: North Facing No SS Internal Weight Boog 75 Wired Polling Rate: 1000hz QMK or VIA Support: No, customization requires to use of our independent driver. Total weight: About 3kg |
Keycap |
Manufacturer: WS PBT Keycap Material: Doubleshot PBT Keycap Thickness: 1.6mm Keycap Profile: Cherry Keys QTY: 81 keys |
Switch |
Product Name: GATERON KS-37B Magnetic Hall Sensor Keyboard Switch Initial Force:30±10gf. Total travel:4.0±0.2mm. Operation Lifetime:150,000,000 Cycles. Bottom Force: 50±10gf. Top Housing Material: Thermoplastic, Transparent Bottom Housing Material: Thermoplastic, Red Stem Material: Thermoplastic, Red Spring Material: Stainless steel |
Highlights |
Dual-rail structure for stability. Square magnet design, with freely adjustable magnetic pole orientation. Supports multi-directional Hall effect sensing. Extending the stem for better switch stability. Integrated spotlight lens design, enhancing light guidance. Every switch features a very tight housing and a very good coat of factory lube. No need to spend hours and hours lubing switches, they are good to go off the pack! |
Package Contents |
Top and bottom cases HE Module(Magnetic Switch, Plate, Gasket, Sound absorbing foam, and PCB) The themed keycaps Tool accessories |
Disclaimer of Stabs |
In the case of mass production, we will lubricate the stabilizer manually to a degree that is better than factory-lubed. However, if an individual pursues an exceptionally perfect tactile experience, he or she will need to lubricate it manually a second time. This is within the acceptable range of quality without affecting the functionality of the keyboard. |
