Description
SPECIFICATIONS:
Form factor |
ATX |
Rated wattage |
1000W |
Efficiency rating |
80 PLUS Gold (up to 90%) |
Modular |
Yes (fully modular) |
Fan size |
135 mm |
Fan bearing |
Fluid Dynamic Bearing |
Dimensions (DxWxH) |
150 x 150 x 86 mm |
PFC type |
Active PFC |
Input voltage range |
100~240 VAC |
Input frequency range |
50~60 Hz |
Protection |
OCP / OVP / OPP / OTP / SCP / UVP |
ATX (24 PIN) |
1 |
EPS (8 PIN) |
2 |
PCI-E 5.0 (16 PIN) |
1 |
PCI-E (6+2 PIN) |
6 |
SATA (15 PIN) |
12 |
MOLEX (4 PIN) |
4 |
FDD (4 PIN) |
1 |
