Description
SPECIFICATIONS:
PANEL SIZE |
23.8" (60cm) |
PANEL RESOLUTION |
1920 x 1080 (FHD) |
REFRESH RATE |
170Hz |
RESPONSE TIME |
1ms (MPRT) |
PANEL TYPE |
IPS |
BRIGHTNESS (NITS) |
250 |
VIEWING ANGLE |
178°(H) / 178°(V) |
ASPECT RATIO |
16:9 |
CURVATURE |
Flat |
CONTRAST RATIO |
1000:1 |
ACTIVE DISPLAY AREA (MM) |
527.04(H) x 296.46(V) |
PIXEL PITCH (H X V) |
0.2745(H) x 0.2745(V) |
SURFACE TREATMENT |
Anti-glare |
DISPLAY COLORS |
16.7M |
DCI-P3 / SRGB |
81.62%/102.57% |
VIDEO PORTS |
1x Display Port (1.2a) 2x HDMI (1.4b) |
USB PORTS |
2x USB 2.0 Type A 1x USB 2.0 Type B |
AUDIO |
1x Earphone out |
KENSINGTON LOCK |
YES |
VESA MOUNTING |
100 X 100 mm |
CONTROL |
5-way OSD navigation joystick |
POWER TYPE |
External Adaptor 20V 2.25A |
POWER INPUT |
100~240V, 50/60Hz |
DYNAMIC REFRESH RATE TECHNOLOGY |
FreeSync Premium |
ACTIVATED RANGE |
48 to 170Hz |
DCR |
100000000:1 |
SIGNAL FREQUENCY |
30~100 KHz(H) 48 to 170 Hz(V) |
ADJUSTMENT (TILT) |
-5° ~ 20° |
ADJUSTMENT (SWIVEL) |
-45° ~ 45° |
ADJUSTMENT (PIVOT) |
-90° ~ 90° |
ADJUSTMENT (HEIGHT) |
0 ~ 130mm |
DIMENSION (W X H X D) |
540.3 x 385.8 x 233.7mm / 21.27 x 15.19 x 9.2 inch |
CARTON DIMENSION (W X H X D) |
606 x 545 x 172mm / 23.9 x 21.46 x 6.77 inch |
FRAMELESS DESIGN |
Yes |
NOTE |
Display Port: 1920 x 1080 (Up to 170Hz) HDMI: 1920 x 1080 (Up to 144Hz) DCI-P3 and sRGB follow CIE1976 Standard |
