Description
SPECIFICATIONS:
Size |
120x120x25 mm |
Mounting hole spacing |
105x105 mm |
Connector & pin-configuration |
4-pin PWM |
Cable length |
40cm |
Bearing |
SSO2 |
Blade geometry |
Heptaperf™ |
Frame technology |
FocusedFlow™ |
Material |
Fibre-glass reinforced polyamide |
Ingress protection |
IP67 |
Motor type |
Three-phase |
Rotational speed (+/- 10%) |
2000 RPM |
Min. rotational speed @ 20% PWM (+/-20%) |
450 RPM |
Airflow |
121,8 m/h |
Acoustical noise |
29,7 dB(A) |
Static pressure |
3,94 mm H₂O |
Input power (typical) |
1,06 W |
Input power (max.) |
1,2 W |
Input current (typical) |
0,09 A |
Max. input current |
0,1 A |
Operating voltage |
12 V |
MTTF |
> 150.000 h |
Scope of delivery |
Fan 4 Fan Screws |
Notes |
The industrialPPC models are high-speed fans for industrial applications. As such, they are not as quiet as other Noctua fans and less suited for low-noise PC builds. Unless you specifically require the higher speeds and performance of the industrialPPC versions, we recommend using models of our other product lines (chromax if you prefer black fans) instead. |
