Description
SPECIFICATIONS:
Size |
120x120x25 mm |
Mounting hole spacing |
105x105 mm |
Connector & pin-configuration |
4-pin PWM |
Cable length |
40cm |
Bearing |
SSO2 |
Blade geometry |
Heptaperf™ |
Frame technology |
FocusedFlow™ |
Material |
Fibre-glass reinforced polyamide |
Ingress protection |
IP67 |
Motor type |
Single-phase |
Rotational speed (+/- 10%) |
3000 RPM |
Min. rotational speed @ 20% PWM (+/-20%) |
750 RPM |
Rotational speed @ 12V (+/- 10%) |
1600 RPM |
Airflow |
186,7 m/h |
Acoustical noise |
43,5 dB(A) |
Static pressure |
7,63 mm H₂O |
Input power (typical) |
3,33 W |
Input power (max.) |
4,32 W |
Input current (typical) |
0,14 A |
Max. input current |
0,18 A |
Operating voltage |
24 V |
Voltage PWM signal |
5 V |
MTTF |
> 150.000 h |
Scope of delivery |
Fan 4 Fan Screws |
