Description
SPECIFICATIONS:
Size |
140x140x25 mm |
Mounting hole spacing |
124,5x124,5 mm |
Connector & pin-configuration |
3-pin |
Cable length |
40cm |
Bearing |
SSO2 |
Blade geometry |
A-Series with Flow Acceleration Channels |
Frame technology |
AAO |
Material |
Fibre-glass reinforced polyamide |
Ingress protection |
IP52 |
Motor type |
Three-phase |
Rotational speed (+/- 10%) |
2000 RPM |
Airflow |
182,5 m/h |
Acoustical noise |
31,5 dB(A) |
Static pressure |
4,18 mm H₂O |
Input power (max.) |
2,16 W |
Max. input current |
0,18 A |
Operating voltage |
12 V |
MTTF |
> 150.000 h |
Scope of delivery |
Fan 4 Fan Screws |
