Description
SPECIFICATIONS:
Size |
140x140x25 mm |
Mounting hole spacing |
124,5x124,5 mm |
Connector & pin-configuration |
4-pin PWM |
Cable length |
20cm + 30cm NA-EC1 extension cable |
Bearing |
SSO2 |
Blade geometry |
A-Series with Flow Acceleration Channels |
Frame technology |
AAO (Advanced Acoustic Optimisation) |
Rotational speed (+/- 10%) |
1500 RPM |
Min. rotational speed @ 20% PWM (+/-20%) |
300 RPM |
Airflow |
140,2 m/h |
Acoustical noise |
24,6 dB(A) |
Static pressure |
2,08 mm H₂O |
Input power (typical) |
0,99 W |
Input power (max.) |
1,3 W |
Input current (typical) |
0,198 A |
Max. input current |
0,26 A |
Operating voltage |
5 V |
MTTF |
> 150.000 h |
Scope of delivery |
30cm extension cable NA-AV1 anti-vibration mounts USB power adaptor cable OmniJoin adaptor set Fan screws |
