Description
SPECIFICATIONS:
Size |
40x40x10 mm |
Mounting hole spacing |
32x32 mm |
Connector & pin-configuration |
4-pin PWM |
Cable length |
20cm + 30cm NA-EC1 extension cable |
Bearing |
SSO2 |
Blade geometry |
A-Series with Flow Acceleration Channels |
Frame technology |
AAO (Advanced Acoustic Optimisation) |
Rotational speed (+/- 10%) |
5000 RPM |
Rotational speed with L.N.A. (+/- 10%) |
3700 RPM |
Min. rotational speed @ 20% PWM (+/-20%) |
1000 RPM |
Airflow |
8,9 m/h |
Airflow with L.N.A. |
6,6 m/h |
Acoustical noise |
19,6 dB(A) |
Acoustical noise with L.N.A. |
12,9 dB(A) |
Static pressure |
1,95 mm H₂O |
Static pressure with L.N.A. |
1,21 mm H₂O |
Input power (typical) |
0,32 W |
Input power (max.) |
0,48 W |
Input current (typical) |
0,03 A |
Max. input current |
0,04 A |
Operating voltage |
12 V |
MTTF |
> 150.000 h |
Scope of delivery |
30cm Extension Cable NA-AV3 anti-vibration mounts OmniJoin Adaptor Set 4-pin y-cable Low-Noise Adaptor (L.N.A.) 4 Fan Screws |
