Description
SPECIFICATIONS:
COOLER SPECIFICATION |
|
Socket compatibility |
AMD sTR5, SP6 |
Height (without fan) |
134 mm |
Width (without fan) |
95 mm |
Depth (without fan) |
95 mm |
Weight (without fan) |
584 g |
Height (with fan) |
134 mm |
Width (with fan) |
95 mm |
Depth (with fan) |
120 mm |
Weight (with fan) |
769 g |
Material |
Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating |
NSPR |
134 |
Max. TDP |
see NSPR |
Fan compatibility |
92x92x25mm |
Scope of delivery |
2x NF-A9 HS-PWM premium fan NA-YC1 4-pin PWM splitter cable NT-H2 high-grade thermal compound (pre-applied) SecuFirm2™ mounting kit for sTR5/SP6 NM-SMT3 mounting tool for mounting bracket installation |
FAN SPECIFICATION |
|
Model |
2x Noctua NF-A9 HS-PWM |
Bearing |
SSO2 |
Max. rotational speed (+/- 10%) |
2500 RPM |
Min. rotational speed @ 20% PWM (+/-20%) |
400 RPM |
Max. airflow |
96,3 m/h |
Max. acoustical noise |
30,6 dB(A) |
Input power (max.) |
1,68 W |
Voltage range |
12 V |
MTTF |
> 150.000 h |
OTHERS |
|
Notes |
Please note that the NH-D9 TR5-SP6 4U is a dedicated version for AMD sTR5/SP6 sockets. Due to its customised larger base, it cannot be used on smaller sockets and is incompatible with Noctua’s mounting kits for these sockets. Please refer to our socket compatibility overview for details. |
