Description
SPECIFICATIONS:
COOLER SPECIFICATION |
|
Socket compatibility |
Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 and AMD AM5, AM4
(Current socket compatibility applies to all coolers purchased since Q4 2021. For older coolers, please refer to this chart.) |
Height (without fan) |
160 mm |
Width (without fan) |
150 mm |
Depth (without fan) |
135 mm |
Height (with fan) |
160 mm |
Width (with fan) |
150 mm |
Depth (with fan) |
135 mm |
Weight (with fan) |
1150 g |
Material |
Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating |
NSPR |
167 |
Max. TDP |
see NSPR |
Fan compatibility |
140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25 |
Scope of delivery |
Black NH-D15S heatsink NF-A15 HS-PWM chromax.black premium fan NA-RC7 Low-Noise Adaptor (L.N.A.) NT-H1 high-grade thermal compound Black SecuFirm2™ mounting kit Black fan-clips for second NF-A15 Noctua Metal Case-Badge |
FAN SPECIFICATION |
|
Model |
NF-A15 HS-PWM chromax.black |
Bearing |
SSO2 |
Max. rotational speed (+/- 10%) |
1500 RPM |
Max. rotational speed with L.N.A. (+/- 10%) |
1200 RPM |
Min. rotational speed @ 20% PWM (+/-20%) |
300 RPM |
Max. airflow |
140,2 m/h |
Max. airflow with L.N.A. |
115,5 m/h |
Max. acoustical noise |
24,6 dB(A) |
Max. acoustical noise with L.N.A. |
19,2 dB(A) |
Input power (max.) |
1,56 W |
Voltage range |
12 V |
MTTF |
> 150.000 h |
