Description
SPECIFICATIONS:
COOLER |
|
Socket compatibility |
Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 and AMD AM5, AM4
(Current socket compatibility applies to all coolers purchased since Q4 2021. For older coolers, please refer to this chart.) |
Height (without fan) |
158 mm |
Width (without fan) |
125 mm |
Depth (without fan) |
45 mm |
Height (with fan) |
158 mm |
Width (with fan) |
125 mm |
Depth (with fan) |
71 mm |
Weight (with fan) |
710 g |
Material |
Nickel plated Copper (base and heat-pipes), aluminium (cooling fins) |
NSPR |
129 |
Max. TDP |
see NSPR |
Fan compatibility |
120x120x25 |
Scope of delivery |
NH-U12S redux heatsink NF-P12 redux-1700 PWM fan 4x NA-AVP1 grey anti-vibration pads Fan mounting clips (one pair) NT-H1 high-grade thermal compound (pre-applied) SecuFirm2™ mounting kit |
FAN |
|
Model |
NF-P12 redux-1700 PWM |
Bearing |
SSO |
Max. rotational speed (+/- 10%) |
1700 RPM |
Min. rotational speed @ 20% PWM (+/-20%) |
450 RPM |
Max. airflow |
120,2 m/h |
Max. acoustical noise |
25,1 dB(A) |
Voltage range |
12 V |
MTTF |
> 150.000 h |
