Description
SPECIFICATIONS:
DIMENSIONS |
|
Height (with feet) |
400 mm (15.75 in) |
Width |
225 mm (8.86 in) |
Depth |
389 mm (15.31 in) |
Volume |
35.0 L |
Weight |
4.8 kg (10.58 lb) |
GENERAL |
|
Enclosure Type |
Micro-ATX Case |
Motherboard Compatibility |
Micro-ATX, Mini-ITX |
Supports Rear-Connecting Motherboard |
Yes (Micro-ATX) |
Materials |
SGCC steel, clear tempered glass |
CLEARANCE |
|
CPU Cooler Height |
170 mm |
GPU Length |
Up to 377 mm (without front fans) Up to 352 mm (with front fans) Up to 317 mm (with front radiator and fans) |
PSU Length |
Up to 185 mm |
Cable Routing Space |
Up to 31.5 mm |
Front Radiator + Fan Thickness |
Up to 63 mm |
Top Radiator + Fan Thickness |
Up to 70 mm |
FRONT I/O PORTS |
|
USB 3.2 Type-A |
1 |
USB 3.2 Gen2x2 Type-C |
1 |
EXPANSION SLOTS |
|
Standard |
4 |
Vertical |
0 |
DRIVE BAYS |
|
2.5" |
1+2 |
3.5" |
1 |
FAN SUPPORT |
|
Front |
2 x 120 mm / 2 x 140 mm |
Top |
2 x 120 mm / 2 x 140 mm |
Bottom |
2 x 120 mm |
Rear |
1 x 120 mm (1 x F120Q (CV) included) |
RADIATOR SUPPORT |
|
Front |
Up to 280 mm |
Top |
Up to 240 mm |
FAN SPECS |
|
Model |
F120Q (CV) |
Speed |
1,350 ± 150 RPM |
Airflow |
60.2 CFM |
Static Pressure |
1.05 mmH2O |
Noise |
24.1 dBA |
Fan Connector |
3-pin |
