SPECIFICATIONS:
Key specs |
Motherboard Support:ATX, Micro-ATX, Mini-ITX Enclosure Type:Mid-Tower Case Material:SGCC Steel, Ultra-Clear Tempered Glass, Dark Tinted Tempered Glass (Black SKU only) |
Dimensions |
Height (with feet):435 mm / 17.13 in Width:287 mm / 11.3 in Depth:415 mm / 16.34 in Weight:9.4 kg |
Compatibility & clearance |
CPU Cooler Height:163 mm / 6.42 in GPU Length:365 mm / 14.37 in PSU Length:200 mm / 7.87 in Cable Management:91 mm / 3.58 in Top Radiator:30 mm / 1.18 in |
Front I/O ports |
USB 3.2 Gen 1 Type-A:2 USB 3.2 Gen 2 Type-C:1 Headset Audio Jack:1 |
Expansion slots |
Standard:7 Vertical:0 |
Drive bays |
2.5":2 3.5":1 |
Fan support |
Front-Right:3 x 120 mm (3 x F120Q included) Top:3 x 120 mm / 2 x 140 mm Bottom:2 x 140 mm Rear:1 x 120 mm Filters:High-Performance Mesh |
Radiator support |
Top:Up to 360 mm Rear:Up to 120 mm |
Fan specs |
Model:F120Q Airflow Fan (Case Version) Speed:1200 ± 240RPM Airflow:62.18 CFM Static:1.05 mm - H2O Noise:25.1 dBA Fan Connector:3-pin |
Inside the box |
H6 Flow 3 x F120Q Airflow (Case Version) Installation Accessories User Guide |
