Description
SPECIFICATIONS:
PICTURE/DISPLAY |
|
Panel Size |
23.8 inch / 60.5 cm |
Aspect ratio |
16:9 |
LCD panel type |
IPS technology |
Backlight type |
W-LED system |
Pixel pitch |
0.2745 x 0.2745 mm |
Brightness |
300cd/m² |
Display colors |
16.7 M (8 bit) |
Color gamut (typical) |
NTSC 88%*, sRGB 105%* |
Contrast ratio (typical) |
1000:1 |
SmartContrast |
50,000,000:1 |
Response time (typical) |
4 ms (Gray to Gray)* |
Viewing angle |
178º (H) / 178º (V) @ C/R > 10 |
Picture enhancement |
SmartImage |
Maximum resolution |
1920 x 1080 @ 75 Hz |
Effective viewing area |
527.04 (H) x 296.46 (V) |
Scanning Frequency |
30 - 85 kHz (H) / 48 - 75 Hz (V) |
sRGB |
Yes |
Flicker-free |
Yes |
Pixel Density |
93 PPI |
LowBlue Mode |
Yes |
Display Screen Coating |
Anti-Glare, 3H, Haze 25% |
EasyRead |
Yes |
CONNECTIVITY |
|
Signal Input |
HDMI 1.4 x 1, DisplayPort 1.4 x 1, USB-C x 1 (upstream, DP Alt mode, Data, PD up to 90W) |
Sync Input |
Separate Sync |
Audio (In/Out) |
Audio out / Microphone in combo jack |
RJ45 |
Ethernet LAN up to 1G*, Wake on LAN |
Signal Output |
DisplayPort out x 1 |
HDCP |
HDCP 1.4 (HDMI / DisplayPort / USB-C); HDCP 2.2 (HDMI / DisplayPort / USB-C) |
HBR3 |
HBR 3 (DisplayPort, USB-C) |
USB Hub |
USB 3.2, Gen 2 / 10 Gbps, USB-C upstream x 1 (Data), USB-A downstream x 4 (with 1 for fast charge B.C 1.2), USB-C downstream x 1 (Data, PD 15W) |
POWER DELIVERY |
|
Max power delivery |
USB-C up to 90W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/4.5A) |
Version |
USB PD version 3.0 |
CONVENIENCE |
|
Built-in Speakers |
5 W x 2 |
Plug & Play Compatibility |
DDC/CI Mac OS X sRGB Windows 11 / 10 / 8.1 / 8 / 7 |
User convenience |
SmartImage Input User Menu Power On/Off |
OSD Languages |
Brazil Portuguese Czech Dutch English French Finnish German Greek Hungarian Italian Japanese Korean Portuguese Polish Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish Ukrainian |
Other convenience |
Kensington lock VESA mount (100x100mm) |
Control software |
SmartControl |
MultiView |
PIP/PBP mode 2x devices |
Built-in webcam |
Pop-up 5.0 megapixel camera with microphone and LED indicator (for Windows Hello) |
KVM |
Yes (USB-C/USB-C) |
Noise cancellation |
Yes |
STAND |
|
Height adjustment |
150 mm |
Pivot |
-/+90 degree |
Swivel |
-/+180 degree |
Tilt |
-5/30 degree |
POWER |
|
Power supply |
Built-in 100-240VAC, 50-60Hz |
Off mode |
Zero watts with AC switch |
On mode |
15.3 W (typ.) (EnergyStar test method) |
Standby mode |
0.3 W (typ.) |
Power LED indicator |
Operation - White Standby mode- White (blinking) |
DIMENSIONS |
|
Packaging in mm (WxHxD) |
600 x 406 x 198 mm |
Product without stand (mm) |
540 x 323 x 51 mm |
Product with stand (max height) |
540 x 500 x 205 mm |
WEIGHT |
|
Product with packaging (kg) |
8.32 kg |
Product with stand (kg) |
5.50 kg |
Product without stand (kg) |
3.90 kg |
OPERATING CONDITIONS |
|
Altitude |
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
Temperature range (operation) |
0°C to 40* °C |
Relative humidity |
20%-80 % |
Temperature range (storage) |
-20°C to 60 °C |
MTBF (demonstrated) |
70,000 hrs (excluded backlight) |
SUSTAINABILITY |
|
Environmental and energy |
PowerSensor LightSensor EnergyStar 8.0 EPEAT* TCO Certified Edge RoHS |
Post consumer recycled plastic |
85% |
Recyclable packaging material |
100 % |
Specific Substances |
Mercury free PVC / BFR free housing |
COMPLIANCE AND STANDARDS |
|
Regulatory Approvals |
CB CE Mark FCC Class B ICES-003 CU-EAC EAEU RoHS TUV Ergo TUV/GS TUV Eye Comfort certified cETLus MEPS RCM |
