Description
SPECIFICATIONS:
PICTURE/DISPLAY |
|
Panel Size |
27"/68.6cm |
Aspect ratio |
16:9 |
LCD panel type |
IPS technology |
Backlight type |
W-LED system |
Pixel pitch |
0.3114x0.3114mm |
Brightness |
300 cd/m² |
Display colors |
16.7 M |
Color gamut (typical) |
Adobe RGB 82.89%; DCI-P3:80.49%, sRGB: 101.8%, NTSC 88.37%* |
Contrast ratio (typical) |
1500:1 |
SmartContrast |
Mega Infinity DCR |
Response time (typical) |
4 ms (Gray to Gray)* |
Viewing angle |
178º (H) / 178º (V) @ C/R > 10 |
Picture enhancement |
SmartImage |
Maximum resolution |
1920x1080 @ 120 Hz |
Effective viewing area |
597.89(H)x336.31(V)mm |
Scanning Frequency |
30 KHz - 140 KHz (H) / 48 Hz - 120 Hz (V) |
sRGB |
Yes |
SoftBlue |
Yes |
Flicker-free |
Yes |
Pixel Density |
82 PPI |
LowBlue Mode |
Yes |
Display Screen Coating |
Anti-Glare, 3H, Haze 25% |
MPRT |
1 ms* |
EasyRead |
Yes |
Adaptive sync |
Yes |
CONNECTIVITY |
|
Signal Input |
HDMI 1.4 x 1, USB-C x 1 (DisplayPort Alt mode) |
Sync Input |
Separate Sync |
Audio (In/Out) |
Audio out |
HDCP |
HDCP 1.4 (HDMI / USB-C) |
USB Hub |
USB 3.2 Gen 1, USB-A downstream x 2 (with 1 fast charge B.C 1.2) |
POWER DELIVERY |
|
Max power delivery |
USB-C: Up to 65W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A) |
Version |
USB PD version 3.0 |
CONVENIENCE |
|
Built-in Speakers |
2W X 2 |
Plug & Play Compatibility |
DDC/CI Mac OS sRGB Windows 11 / 10 |
User convenience |
Power On/Off Menu Volume Input SmartImage |
OSD Languages |
Brazil Portuguese Czech Dutch English Finnish French German Greek Hungarian Italian Japanese Korean Polish Portuguese Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish Ukrainian |
Other convenience |
Kensington lock VESA mount (100x100mm) |
STAND |
|
Tilt |
-5/20 degree |
POWER |
|
Power supply |
Internal 100-240VAC, 50-60Hz |
Off mode |
0.3 W (typ.) |
On mode |
18.8 W (typ.) |
Standby mode |
0.5 W (typ.) |
Power LED indicator |
Operation - White Standby mode- White (blinking) |
DIMENSIONS |
|
Packaging in mm (WxHxD) |
690 x 455 x 141 mm |
Product without stand (mm) |
617 x 357 x 46 mm |
Product with stand (max height) |
617 x 457 x 211 mm |
WEIGHT |
|
Product with packaging (kg) |
7.19 kg |
Product with stand (kg) |
4.49 kg |
Product without stand (kg) |
4.07 kg |
OPERATING CONDITIONS |
|
Altitude |
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
Temperature range (operation) |
0 to 40 °C |
MTBF |
50,000 hrs (excluding backlight) hour(s) |
Relative humidity |
20%-80 % |
Temperature range (storage) |
-20 to 60 °C |
SUSTAINABILITY |
|
Environmental and energy |
RoHS |
Recyclable packaging material |
100 % |
Specific Substances |
PVC / BFR free housing |
COMPLIANCE AND STANDARDS |
|
Regulatory Approvals |
CB CE Mark MEPS UKCA EMF FCC ICES-003 |
