Description
SPECIFICATIONS:
CONNECTIVITY |
|
Signal Input |
HDMI 2.0 x 2, DisplayPort 1.4 x 1, USB-C x 1 |
Sync Input |
Separate Sync |
Sync on Green |
Audio (In/Out) Audio out/Microphone in combo jack |
RJ45 |
Ethernet LAN up to 1G* |
HDCP |
HDCP 1.4 (HDMI/DisplayPort/USB-C); HDCP 2.2 (HDMI/DisplayPort/USB-C) |
HBR3 |
HBR 3 (DisplayPort/USB-C) |
USB Hub |
USB 3.2, Gen 2/10 Gbps, upstream: USB-C1 x 1 (Data DP Alt mode typical PD 96 W) *, USB-C2 x 1 (Data); downstream: USB-A x 4 (with 1 for fast charge B.C 1.2), USB-C3 x 1 (Data, PD 15 W) |
PICTURE/DISPLAY |
|
Panel Size |
34 inch/86.36 cm |
Aspect ratio |
21:9 |
LCD panel type |
VA LCD |
Backlight type |
W-LED system |
Pixel pitch |
0.23175 x 0.23175 mm |
Optimum resolution |
3440 x 1440 @ 60 Hz |
Brightness |
300 cd/m² |
Display colours |
16.7 M (8 bit) |
Colour gamut (typical) |
NTSC area: 104%, sRGB area: 120%* |
Contrast ratio (typical) |
4000:1 |
SmartContrast |
50,000,000:1 |
Response time (typical) |
4 ms (Grey to Grey)* |
Viewing angle |
178º (H)/178º (V) @ C/R > 10 |
Picture enhancement |
SmartImage |
Maximum resolution |
3440 x 1440 @ 100 Hz (HDMI) 3440 x 1440 @ 120 Hz (DP/USBC) |
Effective viewing area |
797.22 (H) x 333.72 (V) - at a 1500R curvature* |
Scanning Frequency |
30–220 kHz (H)/48–120 Hz (V) |
sRGB |
Yes |
Delta E |
< 2 (for sRGB) |
Flicker-free |
Yes |
Pixel Density |
109.68 PPI |
Display Screen Coating |
Anti-Glare, 3H, Haze 25% |
SmartUniformity |
93 ~ 105% |
EasyRead |
Yes |
Adaptive sync |
Yes |
CONVENIENCE |
|
Built-in Speakers |
5 W x 2 |
Plug and Play Compatibility |
DDC/CI Mac OS sRGB Windows 11/10 |
User convenience |
SmartImage Input User Menu Power On/Off |
OSD Languages |
Brazil Portuguese Czech Dutch English French Finnish German Greek Hungarian Italian Japanese Korean Portuguese Polish Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish Ukrainian |
Other convenience |
Kensington lock Earphone hook VESA mount (100 x 100 mm) |
MultiView |
2 x devices PIP/PBP mode |
Noise cancellation |
Yes |
SmartKVM |
Yes (USB-C1/USB-C2) |
STAND |
|
Height adjustment |
180 mm |
Swivel |
-/+ 180 degree |
Tilt |
-5/30 degree |
POWER |
|
ECO mode |
20.5 W (typ.) |
Power supply |
Built-in 100–240 VAC, 50–60 Hz |
Off mode |
Zero watts with AC switch |
On mode |
28.3 W (typ.) (Energy Star test method) |
Standby mode |
0.3 W (typ.) |
Power LED indicator |
Operation - White Standby mode - White (flashing) |
Energy Label Class |
F |
DIMENSIONS |
|
Packaging in mm (W x H x D) |
980 x 525 x 188 mm |
Product without stand (mm) |
807 x 369 x 112 mm |
Product with stand (max height) |
807 x 575 x 281 mm |
WEIGHT |
|
Product with packaging (kg) |
15.65 kg |
Product with stand (kg) |
10.40 kg |
Product without stand (kg) |
7.64 kg |
OPERATING CONDITIONS |
|
Altitude |
Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m) |
Temperature range (operation) |
0°C to 40 °C |
Relative humidity |
20%-80 % |
Temperature range (storage) |
-20°C to 60 °C |
MTBF (demonstrated) |
70,000 hrs (excluded backlight) |
SUSTAINABILITY |
|
Environmental and energy |
PowerSensor LightSensor Energy Star 8.0 EPEAT* TCO Certified RoHS |
Post-consumer recycled plastic |
85%+OBP 5% |
Recyclable packaging material |
100 % |
Specific Substances |
Mercury free PVC/BFR free housing |
COMPLIANCE AND STANDARDS |
|
Regulatory Approvals |
CB CE Mark EPA TUV/GS TUV Ergo TCO 9.0 TCO Certified Edge EAC EAEU RoHS MEPS UKCA EMF FCC ICES-003 TUV Eyesafe certified |
OTHERS |
|
Notes |
* Radius of the arc of the display curvature in mm * Response time value equal to SmartResponse * NTSC Area based on CIE 1976 * sRGB Area based on CIE1931 * For Video transmission via USB-C, your Notebook/device must support USB-C DP Alt mode * Activities such as screen sharing and online streaming over the Internet can impact your network performance. Your hardware and network bandwidth will determine the overall audio and video quality. * For USB-C power and charging function, your Notebook/device must support USB-C standard Power Delivery specifications. Please check with your Notebook user manual or manufacturer for more details. * If your Ethernet connection seems slow, please enter the OSD menu and select USB 3.0 or a higher version that can support the LAN speed up to 1G. * The USB-C power delivery of this display is up to 100 W (96 W in typical). The maximum power delivery will depend on your device. * EPEAT rating is valid only where Philips registers the product. Please visit https://www.epeat.net/ for registration status in your country. |
