Description
SPECIFICATIONS:
LCD panel type |
IPS technology |
Backlight type |
W-LED system |
Panel Size |
39.7 inch / 100.9 cm |
Display Screen Coating |
Anti-Glare, 3H, Haze 25% |
Effective viewing area |
929.28 (H) x 392.04 (V) - at a 2500R curvature* |
Aspect ratio |
21:9 |
Maximum resolution |
5120 x 2160 @ 75 Hz* |
Pixel Density |
140 PPI |
Response time (typical) |
4 ms (Gray to Gray)* |
Brightness |
300 cd/m² |
Contrast ratio (typical) |
1000:1 |
SmartContrast |
80,000,000:1 |
Pixel pitch |
0.1815 x 0.1815 mm |
Viewing angle |
178º (H) / 178º (V) @ C/R > 10 |
Flicker-free |
Yes |
Picture enhancement |
SmartImage |
Display colors |
Color support 1.07 billion colors (8 bit + A-FRC) |
Color gamut (min.) |
DCI-P3 98%* |
Color gamut (typical) |
NTSC 103%*, sRGB 134%* |
HDR |
HDR 10 supported |
Scanning Frequency |
HDMI: 30 - 140 kHz (H) / 30 - 60 Hz (V) ; DP/Thunderbolt 4: 30 - 170 kHz (H) / 48 - 75 Hz (V) |
SmartUniformity |
93 ~ 105% |
Delta E |
< 2 |
sRGB |
Yes |
SoftBlue |
Yes |
EasyRead |
Yes |
Adaptive sync |
Yes |
Signal Input |
HDMI 2.0 x 2, DisplayPort 1.4 x 1, Thunderbolt 4 x 1 (upstream, Data, Video, PD 90W) |
HDCP |
HDCP 1.4 (HDMI / DisplayPort / USB-C), HDCP 2.2 (HDMI / DisplayPort / USB-C) |
HBR3 |
HBR 3 (TBT4 / DisplayPort) |
Signal Output |
Thunderbolt 4 out x 1 (downstream, Data, PD 15W) |
USB Hub |
USB 3.2 Gen 2 / 10 Gbps, USB-B upstream x 1, USB-A downstream x 4 (with 1 for fast charge B.C 1.2), USB-C downstream x 1 (Data, PD 45W) |
Audio (In/Out) |
Audio out / Microphone in combo jack |
RJ45 |
Ethernet LAN up to 1G*, Wake on LAN |
Sync Input |
Separate Sync |
Version |
USB PD version 3.0 |
Max power delivery |
Up to 90 W (5/V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/4.25A) |
Built-in Speakers |
5 W x 2 |
Built-in webcam |
Pop-up 5.0 megapixel camera with microphone and LED indicator (for Windows Hello) |
Noise cancellation |
Yes |
MultiView |
PIP/PBP mode 2x devices |
KVM |
Yes (TBT4/USB-B) |
User convenience |
Mic SmartImage Input User Menu Power On/Off |
Control software |
SmartControl |
OSD Languages |
Brazil Portuguese Czech Dutch English French Finnish German Greek Hungarian Italian Japanese Korean Portuguese Polish Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish Ukrainian |
Other convenience |
Kensington lock Earphone hook VESA mount (100x100mm) |
Plug & Play Compatibility |
DDC/CI Mac OS X sRGB Windows 11 / 10 / 8.1 / 8 |
Height adjustment |
150 mm |
Swivel |
-/+45 degree |
Tilt |
-5/15 degree |
ECO mode |
44.6 W (typ.) |
On mode |
58.3 W (typ.) (EnergyStar test method) |
Standby mode |
0.44 W (typ.) |
Off mode |
Zero watts with AC switch |
Energy Label Class |
G |
Power LED indicator |
Operation - White Standby mode- White (blinking) |
Power supply |
Built-in 100-240VAC, 50-60Hz |
Product with stand(max height) |
948 x 605 x 236 mm |
Product without stand (mm) |
948 x 426 x 109 mm |
Packaging in mm (WxHxD) |
1150 x 565 x 211 mm |
Product with stand (kg) |
13.50 kg |
Product without stand (kg) |
10.30 kg |
Product with packaging (kg) |
17.17 kg |
Temperature range (operation) |
0°C to 40 °C |
Temperature range (storage) |
-20°C to 60 °C |
Relative humidity |
20%-80 % |
Altitude |
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
MTBF (demonstrated) |
70,000 hrs (excluded backlight) |
Environmental and energy |
PowerSensor LightSensor EnergyStar 8.0 EPEAT* RoHS TCO Certified Edge |
Recyclable packaging material |
100 % |
Post consumer recycled plastic |
85% |
Specific Substances |
Mercury free PVC / BFR free housing |
Regulatory Approvals |
CB CE Mark FCC Class B ICES-003 CU-EAC EAEU RoHS TUV Ergo TUV/GS TUV Eyesafe certified cETLus |
