SPECIFICATIONS:
LCD panel type |
IPS technology |
Backlight type |
W-LED system |
Panel Size |
42.51 inch / 108 cm |
Display Screen Coating |
3H, Haze 1% |
Effective viewing area |
941.184 (H) x 529.416 (V) mm |
Aspect ratio |
16:9 |
Maximum resolution |
3840 x 2160 @ 60 Hz* |
Pixel Density |
103.46 PPI |
Response time (typical) |
5 ms (Gray to Gray)* |
Brightness |
400 cd/m² |
Contrast ratio (typical) |
1200:1 |
SmartContrast |
50,000,000:1 |
Pixel pitch |
0.2451 x 0.2451 mm |
Viewing angle |
178º (H) / 178º (V) @ C/R > 10 |
Picture enhancement |
SmartImage |
Display colors |
Color support 1.07 billion colors |
Color gamut (typical) |
NTSC 88%*, sRGB 102%* |
Scanning Frequency |
30 - 140 kHz (H) / 23 - 75 Hz (V) |
SmartUniformity |
96 ~ 105% |
Delta E |
3 |
sRGB |
Yes |
Flicker-free |
Yes |
Signal Input |
VGA (Analog ) DisplayPort 1.2 x 2 HDMI 2.0 x 2 |
HDCP |
HDCP 2.2 (HDMI / DP) |
USB |
USB-B x 1 (upstream), USB 3.2 x 4 (downstream with 1 fast charge B.C 1.2) |
Audio (In/Out) |
PC audio-in Audio out |
Sync Input |
Separate Sync Sync on Green |
Built-in Speakers |
5 W x 2 |
MultiView |
PIP (2x devices) PBP (4x devices) |
User convenience |
SmartImage Input User Menu Power On/Off |
Control software |
SmartControl |
OSD Languages |
Brazil Portuguese Czech Dutch English Finnish French German Greek Hungarian Italian Japanese Korean Polish Portuguese Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish Ukrainian |
Other convenience |
Kensington lock VESA mount (200x200mm) |
Plug & Play Compatibility |
DDC/CI Mac OS X sRGB Windows 10 / 8.1 / 8 / 7 |
ECO mode |
53.3 W (typ.) |
On mode |
100 W (typ.) |
Standby mode |
0.3 W |
Off mode |
Zero watts with Zero switch |
Power LED indicator |
Operation - White Standby mode- White (blinking) |
Power supply |
Built-in 100-240VAC, 50-60Hz |
Product with stand(max height) |
973 x 633 x 259 mm |
Product without stand (mm) |
973 x 561 x 64 mm |
Packaging in mm (WxHxD) |
1070 x 680 x 186 mm |
Product with stand (kg) |
11.78 kg |
Product without stand (kg) |
11.06 kg |
Product with packaging (kg) |
14.74 kg |
Temperature range (operation) |
0°C to 40°C °C |
Temperature range (storage) |
-20°C to 60°C °C |
Relative humidity |
20%-80 % |
Altitude |
Operation: +12,000ft (3,658m) Non-operation: +40,000ft (12,192m) |
MTBF (demonstrated) |
70,000 hrs (excluded backlight) |
Environmental and energy |
RoHS |
Recyclable packaging material |
100 % |
Specific Substances |
PVC / BFR free housing Mercury free |
Regulatory Approvals |
CB SEMKO MEPS RCM CE Mark |
Accessory |
Remote control |
*The maximum resolution works for either USB-C, DP or HDMI input.
*Response time value equal to SmartResponse
*NTSC Area based on CIE1976
*sRGB Area based on CIE1931
