Description
SPECIFICATIONS:
PICTURE/DISPLAY |
|
Panel Size |
23.8"/60.5 cm |
Aspect ratio |
16:9 |
LCD panel type |
IPS technology |
Backlight type |
W-LED system |
Pixel pitch |
0.2745 x 0.2745mm |
Brightness |
300 cd/m² |
Display colors |
16.7 M |
Color gamut (typical) |
Adobe RGB 89%; DCI-P3:93% sRGB: 125%,, NTSC 105%.* |
Contrast ratio (typical) |
1000:1 |
SmartContrast |
Mega Infinity DCR |
Response time (typical) |
1 ms (Gray to Gray)* |
Viewing angle |
178º (H) / 178º (V) @ C/R > 10 |
Picture enhancement |
SmartImage game |
Maximum resolution |
1920x1080 @ 200Hz (HDMI/DP)* |
Effective viewing area |
527.04(H)x296.46(V)mm |
Scanning Frequency |
30-230 KHz(H)/ 48-200 Hz(V) |
sRGB |
Yes |
Flicker-free |
Yes |
Pixel Density |
93 PPI |
LowBlue Mode |
Yes |
Display Screen Coating |
Anti-Glare, 3H, Haze 25% |
Low Input Lag |
Yes |
Adaptive sync |
Yes |
HDR |
HDR 10 supported |
Stark Shadow Boost |
Yes |
Smart MBR |
0.3ms* |
Smart Crosshair |
Yes |
Shadow Boost |
Yes |
CONNECTIVITY |
|
Signal Input |
HDMI 2.0 x 1, DisplayPort 1.4 x 1 |
Sync Input |
Separate Sync |
Audio (In/Out) |
Headphone out |
HDCP |
HDCP 1.4 (HDMI / DP), HDCP 2.2 (HDMI / DP) |
CONVENIENCE |
|
Plug & Play Compatibility |
DDC/CI Mac OS sRGB Windows 11 / 10 |
User convenience |
Power On/Off Menu/OK Input/Up Game Settings/Down SmartImage game/Back |
OSD Languages |
Brazil Portuguese Czech Dutch English Finnish French German Greek Hungarian Italian Japanese Korean Polish Portuguese Russian Spanish Simplified Chinese Swedish Turkish Traditional Chinese Ukrainian |
Other convenience |
Kensington lock VESA mount (100x100mm) LowBlue Mode Stand |
Tilt |
-5/20 degree Power |
Power supply |
Internal 100-240VAC, 50-60Hz |
Off mode |
0.3 W (typ.) |
On mode |
23.4 W (typ.) |
Standby mode |
0.5 W (typ.) |
Power LED indicator |
Operation - White Standby mode- White (blinking) |
DIMENSIONS |
|
Packaging in mm (WxHxD) |
615 x 420 x 126 mm |
Product without stand (mm) |
540 x 325 x 54 mm |
Product with stand (max height) |
540 x 433 x 216 mm |
WEIGHT |
|
Product with packaging (kg) |
5.49 kg |
Product with stand (kg) |
3.21 kg |
Product without stand (kg) |
2.65 kg |
OPERATING CONDITIONS |
|
Altitude |
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
Temperature range (operation) |
0°C to 40 °C |
MTBF |
50,000 (Excluded backlight) hour(s) |
Relative humidity |
20%-80 % |
Temperature range (storage) |
-20°C to 60 °C |
SUSTAINABILITY |
|
Environmental and energy |
RoHS |
Recyclable packaging material |
100 % |
Post consumer recycled plastics |
85%* |
COMPLIANCE AND STANDARDS |
|
Regulatory Approvals |
INMETRO CB CEL CCC CECP CE Mark UKCA EMF FCC ICES-003 |
