Description
SPECIFICATIONS:
CPU |
Intel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz |
CPU Architecture |
64-bit x86 |
Graphic Processors |
Intel® UHD Graphics |
Floating Point Unit |
✓ |
Encryption Engine |
✓ (AES-NI) |
Hardware-accelerated Transcoding |
✓ |
System Memory |
8 GB on board (non-expandable) |
Maximum Memory |
8GB |
Flash Memory |
4GB (Dual boot OS protection) |
Drive Bay |
6 x 3.5-inch SATA 6Gb/s
The system is shipped without HDD. |
Drive Compatibility |
3.5-inch SATA hard disk drives |
Hot-swappable |
✓ |
M.2 Slot |
2 x M.2 2280 PCIe Gen 3 x1 |
SSD Cache Acceleration Support |
✓ |
2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M/10M) |
Wake on LAN (WOL) |
✓ |
Jumbo Frame |
✓ |
PCIe Slot |
1
Card dimensions for PCIe slot：190 x 68.9x 18.76 mm / 7.48 x 2.71 x 0.74 inches. |
USB 2.0 port |
2 |
USB 3.2 Gen 2 (10Gbps) Port |
2 x Type-A |
HDMI Output |
1, HDMI 2.0 (up to 4096 x 2160 @ 60Hz) |
Form Factor |
Tower |
LED Indicators |
Power/Status, LAN, USB, HDD1-6 |
Buttons |
Power, USB copy, Reset |
Dimensions (HxWxD) |
171 × 235 × 226 mm |
Weight (Net) |
2.9 kg |
Weight (Gross) |
4.56 kg |
Operating Temperature |
0 ~ 40˚C (32˚F ~ 104˚F) |
Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
Relative Humidity |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
Power Supply Unit |
120W adapter, 100-240V |
Power Consumption: HDD Sleep Mode |
23.22 W |
Power Consumption: Operating Mode, Typical |
44.02 W Tested with drives fully populated. |
Fan |
2 x 90mm, 12VDC |
System Warning |
Buzzer |
Kensington Security Slot |
✓ |
Max. Number of Concurrent Connections (CIFS) |
1,500 |
