Description
SPECIFICATIONS:
CPU |
AMD Ryzen™ Embedded V1500B 4-core/8-thread 2.2 GHz processor |
CPU Architecture |
64-bit x86 |
Floating Point Unit |
✓ |
Encryption Engine |
✓ (AES-NI) |
System Memory |
32 GB SODIMM DDR4 (2 x 16 GB) |
Maximum Memory |
64 GB (2 x 32 GB) |
Memory Slot |
2 x SODIMM DDR4
Support optional ECC memory For dual-DIMM configuration, you must use a pair of identical DDR4 modules. |
Flash Memory |
5GB (Dual boot OS protection) |
Drive Bay |
5 x 3.5-inch + 4 x 2.5-inch
The system is shipped without HDD/SSD. For the HDD/SSD compatibility list, please visit https://www.qnap.com/compatibility/ |
Drive Compatibility |
3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives
2.5-inch bays: 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch U.2 NVMe PCIe Gen3 x4 solid state drives (2.5-inch Bay #1 & #2) * 2.5-inch bay #1 & #2 support either U.2 NVMe SSDs or SATA 6Gb/s SSDs. ** U.2 NVMe solid-state drives can only be installed in 2.5-inch bay numbers 1 and 2. Installing these drives in other bays will damage the drive connectors. |
Hot-swappable |
✓ |
SSD Cache Acceleration Support |
✓ |
2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M) |
10 Gigabit Ethernet Port |
1 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
Wake on LAN (WOL) |
✓ |
Jumbo Frame |
✓ |
USB 3.2 Gen 2 (10Gbps) Port |
1 x Type-C USB 3.2 Gen 2 3 x Type-A USB 3.2 Gen 2 |
Form Factor |
Tower |
LED Indicators |
HDD 1-5, SSD 1-4, Power/Status, LAN, USB |
Buttons |
Power, Reset, USB Copy |
Dimensions (HxWxD) |
176.5 × 224.6 × 224.1 mm
Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model) |
Weight (Net) |
4.34 kg |
Weight (Gross) |
5.08 kg |
Operating Temperature |
0 - 40 °C (32°F - 104°F) |
Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
Relative Humidity |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
Power Supply Unit |
External, 120 W, AC 100 to 240 V |
Power Consumption: HDD Sleep Mode |
41.2 W |
Power Consumption: Operating Mode, Typical |
55.41 W
Tested with drives fully populated. |
Fan |
1 x 140mm, 12VDC |
System Warning |
Buzzer |
Kensington Security Slot |
✓ |
Max. Number of Concurrent Connections (CIFS) |
2000 |
