Description
SPECIFICATIONS:
GENERAL FEATURE |
|
Application |
Client PCs, Game Consoles |
Rated Capacity |
2,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise) |
Form Factor |
M.2 (2280) |
Interface |
PCIe Gen 4.0 x4, NVMe 2.0 |
Dimension (WxHxD) |
80 x 22 x 2.3 mm |
Weight |
Max 9.0g Weight |
Storage Memory |
Samsung V-NAND 3-bit MLC |
Controller |
Samsung In-house Controller |
Cache Memory |
Samsung 2GB Low Power DDR4 SDRAM |
SPECIAL FEATURE |
|
TRIM Support |
Supported |
S.M.A.R.T Support |
Supported |
GC (Garbage Collection) |
Auto Garbage Collection Algorithm |
Encryption Support |
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
WWN Support |
Not supported |
Device Sleep Mode Support |
Yes |
PERFORMANCE |
|
Sequential Read |
Up to 7,450 MB/s * |
Sequential Write |
Up to 6,900 MB/s * |
Random Read (4KB, QD32) |
Up to 1,400,000 IOPS * |
Random Write (4KB, QD32) |
Up to 1,550,000 IOPS * |
Random Read (4KB, QD1) |
Up to 22,000 IOPS * |
Random Write (4KB, QD1) |
Up to 80,000 IOPS * * Performance may vary based on system hardware & configuration |
ENVIRONMENT |
|
Average Power Consumption (system level) |
Average: 5.5 W* Maximum: 8.5 W (Burst mode)* |
Power Consumption (Idle) |
Max. 55 mW * |
Allowable Voltage |
3.3 V ± 5 % Allowable voltage |
Reliability (MTBF) |
1.5 Million Hours Reliability (MTBF) |
Operating Temperature |
0 - 70°C Operating Temperature |
Shock |
1,500 G & 0.5 ms (Half sine) * Actual power consumption may vary depending on system hardware & configuration |
SOFTWARE |
|
Management SW |
Magician Software for SSD management |
