Description
SPECIFICATIONS:
DISPLAY |
|
Diagonal Size |
50" |
Panel Type |
IPS |
Resolution |
3,840 x 2,160 |
Pixel Pitch (HxV) |
0.285x0.285mm |
Brightness (Typ) |
500 nit |
Contrast Ratio |
1,200:1 |
Viewing Angle (H/V) |
178/178 |
Response Time |
8ms |
Color Gamut |
72% (NTSC) |
Glass Haze |
25% |
H-Scanning Frequency |
30~81kHz |
Maximum Pixel Frequency |
594MHz |
V-Scanning Frequency |
48~75Hz |
Contrast Ratio (Dynamic) |
Mega |
Operation Time Support |
24/7 |
CONNECTIVITY |
|
HDMI In |
3 |
DP In |
1 |
Version of HDMI |
2 |
Version of DP |
1.2 |
Version of HDCP |
2.2 |
USB |
2 |
IR In |
Yes |
Audio In |
No |
Audio Out |
Stereo Mini Jack |
RS232 In |
Yes |
RS232 Out |
Yes |
RJ45 In |
Yes |
WiFi |
Yes |
Bluetooth |
Yes |
POWER |
|
Power Supply |
AC100-240V 50/60Hz |
Power Consumption (On Mode) |
132 W |
Power Consumption (Sleep Mode) |
0.5 W |
DIMENSION |
|
Set Dimension (WxHxD) |
1124.1 x 644.8 x 28.5 mm |
Package Dimension (HxWxD) |
1246 x 761 x 131 mm |
WEIGHT |
|
Net Weight |
11.8 kg |
Package Weight |
14.9 kg |
OPERATION CONDITIONS |
|
Temperature |
0℃~ 40℃ |
Humidity |
10 ~ 80%, non-condensing |
MECHANICAL SPECIFICATION |
|
VESA Mount |
200 x 200 mm |
Bezel Width |
11.5mm (even) |
Frame Material |
Non-Glossy |
SOC |
|
OS Version |
Tizen 7.0 |
Flash Memory Size |
16GB |
CERTIFICATION AND COMPLIANCE |
|
EMC |
Class B |
Safety |
60950-1, 62368-1 |
