Description
SPECIFICATIONS:
DISPLAY |
|
Diagonal Size |
32" |
Panel Type |
New Edge, 60Hz |
Resolution |
1,920 x 1,080 |
Pixel Pitch (HxV) |
0.36375 x 0.36375 (mm) |
Brightness (Typical) |
400(without glass), 300(with glass) |
Contrast Ratio |
5000:1(without glass) |
Viewing Angle (H/V) |
178/178 |
Response Time |
8ms |
Color Gamut |
72% |
Glass Haze |
2% (without Glass) |
H-Scanning Frequency |
30 ~ 81kHZ |
Maximum Pixel Frequency |
594MHz |
V-Scanning Frequency |
48 ~ 75HZ |
Contrast Ratio (Dynamic) |
Mega DCR |
CONNECTIVITY |
|
HDMI In |
2 |
DP In |
Yes |
USB |
2 |
IR In |
Yes |
HDBaseT In |
No |
Audio In |
No |
Audio Out |
Stereo Mini Jack |
Video Out |
Yes |
RS232 In |
Yes |
RS232 Out |
Yes |
RJ45 In |
Yes |
RJ45 Out |
No |
WiFi |
Yes |
3G Dongle |
No |
Bluetooth |
Yes |
POWER |
|
Power Supply |
AC100-240V 50/60Hz |
Power Consumption (On Mode) |
72 |
Power Consumption (Sleep Mode) |
0.5 W |
DIMENSION |
|
Set Dimension (WxHxD) |
744.4 x 444.6 x 48.2 mm |
Package Dimension (HxWxD) |
872 x 565 x 133 mm |
WEIGHT |
|
Net Weight |
8.3 kg |
Package Weight |
11.1 kg |
OPERATION CONDITIONS |
|
Temperature |
0℃~ 40℃ |
Humidity |
10 ~ 80%, non-condensing |
MECHANICAL SPECIFICATION |
|
VESA Mount |
200 x 200 mm |
Bezel Width |
24.5(U/D), 21.5(L/R) |
Frame Material |
Non-Glossy |
INTERNAL PLAYER (MAGICINFO) |
|
MagicInfo Daisychain Videowall Support |
Yes |
TOUCH |
|
Touch Technology |
Capative |
CERTIFICATION AND COMPLIANCE |
|
EMC |
Class B |
Safety |
60950-1 |
