Description
SPECIFICATIONS:
OVERVIEW |
|
Aspect Ratio |
16:9 |
Brightness (Typical) |
350 cd/㎡ |
Contrast Ratio Static |
1000:1(Typ) |
Resolution |
QHD (2,560 x 1,440) |
Response Time |
5ms |
Viewing Angle (H/V) |
178/178 |
Refresh Rate |
Max 100Hz |
DISPLAY |
|
Screen Size (Class) |
24 |
Flat / Curved |
Flat |
Active Display Size (HxV) (mm) |
526.848 x 296.352 mm |
Aspect Ratio |
16:9 |
Panel Type |
IPS |
Brightness (Typical) |
350 cd/㎡ |
Brightness (Min) |
280 cd/㎡ |
Contrast Ratio Static |
1000:1(Typ) |
Contrast Ratio (Dynamic) |
Mega |
HDR(High Dynamic Range) |
HDR10 |
Resolution |
QHD (2,560 x 1,440) |
Response Time |
5ms |
Viewing Angle (H/V) |
178/178 |
Colour Support |
Max 1.07B |
sRGB Coverage |
99% (Typ) |
Refresh Rate |
Max 100Hz |
GENERAL FEATURE |
|
Energy Saving Solution |
Yes |
Eye Saver Mode |
Yes |
Flicker Free |
Yes |
Picture-In-Picture |
Yes |
Picture-By-Picture |
Yes |
Image Size |
Yes |
Daisy Chain |
Yes |
Windows Certification |
Windows11 |
Off Timer Plus |
Yes |
Auto Source Switch |
Auto Source Switch+ |
Adaptive Picture |
Yes |
KVM Switch |
Yes |
SMART SERVICE |
|
Smart Type |
No |
INTERFACE |
|
Display Port |
1 EA |
Display Port Version |
1.4 |
HDCP Version (DP) |
2.2 |
Display Port Out |
1 |
Display Port Out Version |
1.4 |
HDMI |
1 EA |
HDMI Version |
2.0 |
HDCP Version (HDMI) |
2.2 |
Headphone |
Yes |
USB Hub |
3 |
USB Hub Version |
3.0x3ea |
USB-C |
1 EA |
USB-C Charging Power |
90W |
USB-B Upstream Port |
1 |
HDCP Version (USB-C) |
2.2 |
Ethernet (LAN) |
1 EA |
AUDIO |
|
Speaker |
No |
OPERATION CONDITIONS |
|
Temperature |
10 - 40 ℃ |
Humidity |
10 - 80 (Non-Condensing) |
DESIGN |
|
Front Colour |
BLACK |
Rear Colour |
BLACK |
Stand Colour |
Black |
Stand Type |
HAS PIVOT |
HAS (Height Adjustable Stand) |
120.0 mm (±5.0 mm) |
Tilt |
-2.0 (±2.0) - 25.0˚ (±2.0˚) |
Swivel |
-30.0 (±3.0) - 30.0˚ (±3.0˚) |
Pivot |
-92.0 (±2.0) - 92.0˚ (±2.0˚) |
Wall Mount |
100 x 100 |
ECO |
|
TCO Certified |
Yes |
EPEAT |
Gold (AU Only) |
Carbon Footprint |
Yes |
Recycled Plastic |
OVER 50 % |
Power |
|
Power Supply |
AC 100 - 240 V |
Power Consumption (Max) |
160 W |
Power Consumption (Typ) |
30.0 W |
Power Consumption (DPMS) |
0.5 W |
Power Consumption (Off Mode) |
0.30 W |
Power Consumption (Yearly) |
113 kWh/year |
Type |
Internal Power |
DIMENSION |
|
Set Dimension with Stand (WxHxD) |
540.7 x 535.9 x 220 mm |
Set Dimension without Stand (WxHxD) |
540.7 x 327.2 x 41.7 mm |
Package Dimension (WxHxD) |
626.0 x 171.0 x 484.0 mm |
WEIGHT |
|
Set Weight with Stand |
5.4 kg |
Set Weight without Stand |
2.9 kg |
Package Weight |
8.1 kg |
ACCESSORY |
|
Power Cable Length |
1.5 m |
USB Type-C Cable |
Yes |
