Description
SPECIFICATIONS:
Colour |
Silver |
||||||
Max. DC Output |
1000W |
||||||
Power density |
1338W per liter |
||||||
Load Range |
Output Max.(Amps) Min.(Amps) Range (%) Line Reg.(%) Ripple(mVp-p) |
+3.3V 25A 1.0A ±5% ±1% 50mV |
+5V 25A 1.0A ±5% ±1% 50mV |
+12V 83A 1.0A ±5% ±1% 120mV |
+5VSB 3.5A 0.1A ±5% ±1% 50mV |
-12V 0.8A 0A ±5% ±1% 120mV |
|
Combined +3.3V & +5V |
170W |
||||||
Combined +12V |
996W |
||||||
Input Voltage |
90 ~ 264 Vrms |
||||||
Input Frequency Range |
47Hz ~ 63Hz |
||||||
PFC |
Active PFC (PF>0.9 at full load) |
||||||
Efficiency |
≥87% & <89% overall efficiency with single modular power supply |
||||||
MTBF |
>100,000 hours |
||||||
Operating temperature |
0°C ~ 45°C |
||||||
Protection |
Over Current Protection Over Voltage Protection Short Circuit Protection Over Temperature Protection |
||||||
Connectors |
1 x 24 / 20-Pin motherboard connector 2 x 8 / 4-Pin EPS / ATX 12V connectors 2 x 8 / 6-Pin PCIe connectors 6 x SATA connectors 9 x 4-Pin Peripheral connectors 1 x 4-Pin Floppy connector 1 x 2-Pin TTL connector 1 x 2-Pin PW1 connector 1 x 2-Pin PW2 connector 1 x PM Bus connector |
||||||
Cooling System |
40mm PWM fans |
||||||
Fan speed |
22,000 RPM |
||||||
Noise Level |
62.5 dBA maximum |
||||||
LED indicator |
Power Supply Condition No AC power to all PSU AC present / only standby output on Power supply DC output ON and OK Power supply failure |
Power System Status OFF Red Green Red |
|||||
Form factor |
1+1 2U redundant form factor |
||||||
Dimension |
102mm (W) x 82mm (H) x 231mm (D) (Housing with bracket, without handle) 84mm (W) x 82mm (H) x 217mm (D) (Housing without bracket) 78mm (W) X 39mm (H) X 190mm (D) (Module only without handle)
4.02" (W) x 3.23" (H) x 9.09" (D) (Housing with bracket, without handle) 3.31" (W) x 3.23" (H) x 8.54" (D) (Housing without bracket) 3.07" (W) x 1.54" (H) x 7.48" (D) (Module only without handle) |
||||||
Weight |
3.16 kg |
||||||
