Description
SPECIFICATIONS:
Max. DC Output |
600W |
Power density |
803W per litre |
Colour |
Silver |
Combined +3.3V & +5V |
170W |
Load Range |
Output +3.3V +5V +12V +5VSB -12V Max.(Amps) 25A 25A 50A 3.5A 0.8A Min.(Amps) 1.0A 1.0A 1.0A 0.1A 0A Range (%) ±5% ±5% ±5% ±5% ±5% Line Reg.(%) ±1% ±1% ±1% ±1% ±1% Ripple(mVp-p) 50mV 50mV 120mV 50mV 120mV |
Combined +12V |
600W |
Input Voltage |
90 ~ 264 Vrms |
Input Frequency Range |
47Hz ~ 63Hz |
PFC |
Active PFC (PF>0.9 at full load) |
Efficiency |
≥87% & <89% overall efficiency with single modular power supply |
MTBF |
>100,000 hours |
Operating temperature |
0°C ~ 45°C |
Protection |
Over Current Protection Over Voltage Protection Short Circuit Protection Over Temperature Protection |
Connectors |
1 x 24 / 20-Pin motherboard connector 2 x 8 / 4-Pin EPS / ATX 12V connectors 2 x 8 / 6-Pin PCIe connectors 6 x SATA connectors 9 x 4-Pin Peripheral connectors 1 x 4-Pin Floppy connector 1 x 2-Pin TTL connector 1 x 2-Pin PW1 connector 1 x 2-Pin PW2 connector 1 x PM Bus connector |
Cooling System |
40mm PWM fans |
Form factor |
1+1 2U redundant form factor |
Noise Level |
62.5 dBA maximum |
Fan speed |
22,000 RPM |
Dimension |
102mm (W) x 82mm (H) x 231mm (D) (Housing with bracket, without handle) 84mm (W) x 82mm (H) x 217mm (D) (Housing without bracket) 78mm (W) X 39mm (H) X 190mm (D) (Module only without handle) 4.02" (W) x 3.23" (H) x 9.09" (D) (Housing with bracket, without handle) 3.31" (W) x 3.23" (H) x 8.54" (D) (Housing without bracket) 3.07" (W) x 1.54" (H) x 7.48" (D) (Module only without handle) |
Weight |
3.13 kg |
