SilverStone Alta F2 Tempered Glass ATX Case - Black

Motherboard

SSI-EEB, SSI-CEB, Extended ATX, XL-ATX , ATX, Micro-ATX, Mini-ITX

Drive bay

Internal

3.5" x 4 (compatible with 2.5" x 4)

3.5" x 4

2.5" x 3

Cooling system

Front

Top

Bottom

120mm x 2 / 140mm x 2

120mm x 4 / 140mm x 1

180mm x 3 (180mm x 3 Air Penetrator 184i PRO fans included)

Radiator support

Front

Top

Bottom

120mm / 140mm / 240mm / 280mm

120mm / 140mm / 240mm / 360mm / 480mm

120mm / 140mm / 240mm / 280mm / 360mm (120mm x 3) / 360mm (180mm x 2) / 420mm / 480mm / 540mm / 560mm

Limitation of CPU cooler

205mm

Expansion slot

9+4+4

Limitation of expansion card

Length (vertical): 354mm

Length (horizontal): 604mm (with front hard drive cages removed)

Width: 209mm

Power supply

Standard PS2 (ATX) + Standard PS2 (ATX) under 1200W (Occupies the rear 4+4 expansion slots)

Limitation of PSU

220mm

Front I/O port

USB Type-C x 1

USB 3.0 x 4

Combo audio x 1

Dimension

261mm (W) x 576mm (H) x 658mm (D), 99 Liters

10.28” (W) x 22.68” (H) x 25.91” (D), 99 Liters

Net weight

21.14 kg
