Description
SPECIFICATIONS:
Material |
Copper heat pipes with aluminum fins |
Application |
Intel LGA 2066/2011/1700/1200/115x/1366/775 AMD Socket AM4/AM5/AM3/AM2/FM2/FM1* |
Heat Pipe Type |
Ø6mm heat-pipe x 4 |
Fan |
Dimension: 120mm (W) x 25mm (H) x 120mm (D) Speed: 300 ~ 2200 RPM Noise level: 6.2 ~ 34.4 dBA Rated Current: 0.23A Max airflow: 69.26 CFM Max air pressure: 2.36mmH2O Connector: 4 pin PWM & 4-1 pin ARGB (5V LED) Bearing: Hydraulic bearing MTTF: 40,000 hours |
Dimension |
128mm (W) x 154mm (H) x 75mm (D) |
Net weight |
670g |
* Please use the original backplate on your AMD platform motherboard.
** Please check to make sure the control box and motherboard RGB port that you want to connect are the same as AR12-TUF’s RGB port definition. Incorrect connection may cause malfunction or damage.
