Description
NOTE: Compatibility with other components may vary based on system configuration. Please ensure accurate measurements before installation.
SPECIFICATIONS:
Chassis form factor |
4U |
Motherboard |
SSI-EEB * , SSI-CEB, Extended ATX, ATX, Micro-ATX, Mini-ITX
* The combined length of 5.25” devices and the motherboard equals 481mm. Please refer to the manual for a detailed illustration of various motherboard form factor tolerances when 5.25” devices are to be installed within this constraint. |
Material |
Steel |
Main metal thickness |
1.0mm ~ 1.2mm |
Drive Support |
Internal: 3.5" x 8 2.5" x 4 |
Power Supply |
PS2 (ATX) / Mini Redundant / 2U Redundant |
Cooling system |
Front: 120mm x 3 Rear: 80mm x 2 (2 x 80mm fans included) |
Radiator support |
Front: 120mm / 240mm / 360mm |
Limitation of CPU cooler |
130mm (with GPU holder) 148mm (without GPU holder) |
Expansion card |
Length 340mm Width w/ GPU holder: 116mm Width w/o GPU holder: 154mm |
Expansion Slot |
8 |
Front I/O Port |
USB Type-C x 1 * USB 3.0 x 2
* A USB3 Type-C internal cable with a total length of 800mm is provided. When connecting external storage devices, it is advisable to avoid using overly lengthy cables, as excessive cable length can potentially lead to a decrease in transfer speed. |
Front buttons |
Power On/Off System Reset |
LED Indicators |
Power LED x 1: Blue HDD Access x 1: Green LAN LED x 2: Green |
Dimension |
438mm (W) x 176mm (H) x 500mm (D), 38.54 Liters 17.24" (W) x 6.93" (H) x 19.69" (D), 38.54 Liters |
Net Weight |
10.44 kg |
