Description
SPECIFICATIONS:
Chassis form factor |
5U |
Motherboard |
SSI-EEB, SSI-CEB, Extended ATX, ATX, Micro-ATX, Mini-ITX |
Material |
Steel |
Drive Bay |
Internal 3.5" x 2 (compatible with 2.5" x 3) + 3.5" x 2 (compatible with SFX PSU) 2.5" x 4 |
Power Supply |
Primary PSU slot: PS2 (ATX) / Mini Redundant Secondary PSU slot: SFX (occupies 3.5" bracket) |
Limitation of PSU |
160mm~190mm (Removal of 3.5" drive cage eliminates PSU depth limitation) |
Cooling system |
Front 120mm x 3 / 180mm x 2 (2 x Air Penetrator 184i PRO fans included) Rear Rear I/O: 120mm x 1 / 140mm x 1 Rear fan cage: 80mm x 2 |
Radiator support |
Front 120mm x 3 / 120mm x 1 + 240mm x 1 / 360mm x 1 (120mm x 3) / 360mm x 1 (180mm x 2)
Rear 120mm x 1 |
Limitation of CPU cooler |
Height w/ expansion card retainer: 181mm Height w/o expansion card retainer: 192mm |
Expansion card |
Length: 455mm (without installing front fans and radiators) Width w/ expansion card retainer: 157mm Width w/o expansion card retainer: 198mm |
Expansion Slot |
8 |
Front I/O Port |
USB Type-C x 1 USB 3.0 x 2 |
LED indicator |
Power status x 1 HDD activity x 1 LAN activity x 2 |
Dimension |
Incl. rear fan cage: 440mm (W) x 220mm (H) x 530mm (D), 51.3 liters Excl. rear fan cage: 440mm (W) x 220mm (H) x 485mm (D), 46.95 liters Incl. rear fan cage: 17.3" (W), 8.66" (H), 20.87" (D) Excl. rear fan cage: 17.3" (W), 8.66" (H), 19.1" (D) |
Net Weight |
10.6 kg |
Extra |
Side switch for chassis intrusion security |
