Description
SPECIFICATIONS:
Connector(s) |
|
1 - Connector Type(s) |
PCI Express x4 |
1 - Internal Ports |
SATA Power (15 pin) LP4 (4 pin; Large Drive Power) |
4 - External Ports |
USB Type-A (9 pin) USB 3.0 (5 Gbps) |
Environmental |
|
Operating Temperature |
0°C to 50°C (32°F to 122°F) |
Storage Temperature |
-20°C to 60°C (-4°F to 140°F) |
Humidity |
5~85% RH |
Hardware |
|
Ports |
4 |
Interface |
USB 3.0 |
Bus Type |
PCI Express |
Card Type |
Standard Profile (LP bracket incl.) |
Port Style |
Integrated on Card |
Industry Standards |
USB 3.0 Specification Rev. 1.0 |
Chipset ID |
Renesas/NEC - µPD720202 |
Packaging Information |
|
Package Height |
1.6 in [41.0 mm] |
Package Length |
8.2 in [20.8 cm] |
Shipping (Package) Weight |
7.1 oz [202.0 g] |
Package Width |
5.7 in [14.5 cm] |
Performance |
|
Maximum Data Transfer Rate |
5Gbps per port - 20Gbps Total |
Maximum Cable Length |
9.8 ft [3 m] |
Type and Rate |
USB 3.0 - 5 Gbit/s |
UASP Support |
Yes |
Physical Characteristics |
|
Weight of Product |
3.2 oz [92.0 g] |
Material |
Steel |
Product Length |
6.6 in [16.7 cm] |
Product Width |
0.6 in [15.0 mm] |
Product Height |
4.7 in [12.0 cm] |
OS Compatibility |
Windows® Vista, 7, 8, 8.1, 10 |
System and Cable Requirements |
Available PCI Express x4 or greater slot |
