Description
SPECIFICATIONS:
Connector(s) |
|
1 - Drive Connectors |
SATA Data & Power Combo (7+15 pin) |
1 - Host Connectors |
USB Type-C (24 pin) USB 3.1 (10Gbps) |
Environmental |
|
Operating Temperature |
0°C to 70°C (32°F to 158°F) |
Storage Temperature |
-10°C to 55°C (14°F to 131°F) |
Humidity |
40% ~ 50% RH |
Hardware |
|
Interface |
USB 3.1 Gen 2 |
Bus Type |
USB 3.1 Gen 2 |
Number of Drives |
1 |
Drive Size |
2.5in |
Compatible Drive Types |
SATA |
Number of 2.5 inch bays |
1 |
Chipset ID |
ASMedia - ASM235CM |
Packaging Information |
|
Shipping (Package) Weight |
1.4 oz [41 g] |
Package Length |
8.7 in [22 cm] |
Package Width |
7.7 in [19.5 cm] |
Package Height |
0.2 in [5 mm] |
Performance |
|
Maximum Data Transfer Rate |
10 Gbps |
Type and Rate |
USB 3.1 Gen 2 - 10 Gbit/s |
UASP Support |
Yes |
4Kn Support |
Yes |
TRIM Support |
Yes |
Hardware Raid Supported |
No |
Max Drive Capacity |
Currently tested with hard drives up to 2TB at 7200 RPM |
Hot Swap Capability |
Yes |
MTBF |
1,665,032 hours |
Physical Characteristics |
|
Weight of Product |
1.0 oz [29.2 g] |
Colour |
Black |
Material |
Plastic |
Product Length |
20.0 in [50.8 cm] |
Product Width |
1.7 in [43 mm] |
Product Height |
0.2 in [5 mm] |
Software |
|
OS Compatibility |
OS independent; No software or drivers required |
Note |
Windows 7 and earlier Windows versions do not support TRIM with USB to SATA devices. |
