Description
SPECIFICATIONS:
Connector(s) |
|
1 - Connector Type(s) |
HDMI DisplayPort VGA (15 pin, High Density D-Sub) Ethernet Gigabit USB 3.1 USB Type C (10 pin, Gen 2, 10 Gbps) |
2 - Connector Type(s) |
USB 3.1 USB Type-A (9 pin, Gen 2, 10 Gbps) |
1 - Host Connectors |
USB 3.1 USB Type C (10 pin, Gen 2, 10 Gbps) |
Environmental |
|
Operating Temperature |
0 to 50⁰C |
Storage Temperature |
-20 to 70⁰C |
Humidity |
0% to 95%(non-condensing) at 25°C |
Hardware |
|
4K Support |
Yes |
Fast-Charge Port(s) |
Yes |
Displays Supported |
1 |
Ports |
6 |
Audio |
No |
Interface |
USB 3.2 Gen 2 - 10 Gbit/s |
Bus Type |
USB 3.1 Gen 2 |
USB Pass-Through |
Yes |
Industry Standards |
1 Gigabit connectivity to any 1000Base-T device (IEEE802.3ab Compliant) |
Chipset ID |
Genesys Logic GL9510 |
Packaging Information |
|
Package Height |
1.5 in [37.0 mm] |
Package Length |
5.7 in [14.5 cm] |
Shipping (Package) Weight |
9.8 oz [278.0 g] |
Package Width |
5.2 in [13.3 cm] |
Performance |
|
Maximum Data Transfer Rate |
10 Gbps |
Maximum Digital Resolutions |
4K 60Hz |
Type and Rate |
USB 3.2 Gen 2 - 10 Gbit/s |
Physical Characteristics |
|
Colour |
Black & Gray |
Product Height |
1.3 in [32.5 mm] |
Product Length |
3.5 in [90.0 mm] |
Weight of Product |
7.1 oz [201.0 g] |
Product Width |
3.5 in [90.0 mm] |
Material |
Plastic |
OS Compatibility |
Windows 10 |
