Surveilist 36CH H.265 NVR36CH Max. Input 4K/12M Support

Save $21.00

Price:
Sale price$102.99 Regular price$123.99

Description

Product Name: Surveilist 36CH H.265 NVR36CH Max. Input 4K/12M Support
Model Number: NVRCB3636
Brand: Surveilist
Manufacturer Warranty: 1 Year-

SYSTEM

Main Processor

ARM Cortex A17 Quad-core Processor

Operating System

Embedded LINUX

VIDEO

Input

36CH (4000×3000, 3840×2160, 2592x1944, 2048x1536, 1920×1080, 1280×960, 1280×720, etc)

Output

1 VGA, 1 HD

AUDIO

Input

1 Port RCA

Output

1 Port RCA(Linear, 1kΩ)

Audio Bit Rate

64kbps

Audio Compression
  standard

AAC,G711u, G711a, ADPCM_DVI4

Intercom

support (two-way)

ALARM

Sensor Input

NO

Output

NO

Motion Detection

36 Channel, MD Zones: 396 (22 × 18)

Trigger Events

Recording, Email, FTP, Snapshot, Buzzer and Screen Tips

DISPLAY

HD Output1

4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

HD Output2

/

VGA

1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

Display Split

36CHxD1/25CHxD1/16CHxD1/9CHxD1/4CHxD1/1CHx1080P/1CHx3MP/1CHx4MP/1CHx5MP/1CHx4k/1CHx12MP

Digital Zoom

YES

OSD

Camera Title, Time, Recording, Motion Detection, Event Alarm

RECORDING

Video Compression

H265/H264/H265+/H264+

Resolution

12MP(4000×3000),4k(3840×2160),5MP(2592×1944),4MP(2688×1520/2560×1440),
  3MP(2048×1536),1080P(1920×1080),960P(1280x960),720P(1280×720),D1 (720×576/720×480)

Record Rate

PAL :12MP@25×25fp,4k@30×25fp,5MP@36×25fp,4MP@36x25fp,3MP@36×25fp,
  1080P@36×25fp, 960P@36×25fp,720P@36×25fp, D1@36×25fp
  NTSC: 12MP@25×30fp,4k@30×30fp,5MP@36×30fp,4MP@36×30fp,3MP@36×30fp,
  1080P@36×30fp, 960P@36×30fp, 720P@36×30fp, D1@36×30fp

Record Mode

Manual\Timer\Motion Detection\Smart Event

PLAYBACK & BACKUP

Local Sync Playback

3CH 12MP@15fps, 4CH 4K@30fps, 6CH 5MP@30fps, 8CH 4MP@30fps, 10CH 3M@30fps, 16CH 1080P@30fps,
  16CH 960P@30fps, 16CH 720P@30fps,16CH D1@30fps

Decode Capability

4CH 4K(3840×2160)@30fps

Remote Sync Playback

YES

Search Mode

ALL, Channel, Manual, Time, Date, Motion Detection,Event Alarm,Tag search

Playback Functions

Play, Pause, Stop, Rewind, Fast play, Slow Play, Full Screen, Frame Play ,Frame Rewind, Digital Zoom,tag,clip

Backup Mode

USB Device/Network

NETWORK

Interface

1 RJ45 10M/100/1000M Adaptive Ethernet Interface

Incoming Bandwidth

300MB

Network Functions

TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p,PPPOE

Onvif

onvif S,onvif T

Web Browser

Edge,IE8-11, Google Chrome , Firefox ,Safari

CMS Software

Support  Windows 7/ Windows 8/Windows 10/MAC OS

Cloud Support

Yes

Smart Phone

iPhone, iPad, Android, Android Pad

POE

/

WIFI  UI

/

STORAGE

Interface Type

2 SATA Hard Disk Interface (3.5" SATA)

Capacity

Up to 12TB capacity

eSATA

/

GENERAL

Language

Traditional Chinese, Simplified Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian,
  German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, Korean, Dutch, Greek, Vietnamese

USB Interface

1 USB 2.0 Interfaces ,1 USB 3.0 Interface

RS485

/

Power Supply

DC12V/4A

Working Environment

-10~55/10~90%

Dimension(W×D×H)

310*295*46(mm)

Weight

3.5KG (without HDD)
