Description
SPECIFICATIONS:
CPU |
Dual core 1.7 GHz |
Hardware Acceleration Engine |
Layer 4 / Layer 7 |
Memory |
512 MB DDR3 |
Antenna Type |
4x4 MIMO Omni-directional high-gain dipole (2.4GHz / 5GHz) |
LAN Port |
Gigabit (RJ-45) x 4 Gigabit (RJ-45) x 3 (Dual WAN) |
WAN Port |
Gigabit (RJ-45) x 1 Gigabit (RJ-45) x 2 (Dual WAN) |
External Ports |
USB 3.0 x 1 (5V, 0.9A power output) USB 2.0 x 1 (5V, 0.5A power output) SD card reader x 1 (SDXC, SDHC) |
IEEE 802.11ac |
IEEE 802.11a/b/g/n/ac Simultaneous dual-band Wi-Fi 5GHz: 1.73Gbps 2.4GHz: 800Mbps |
IEEE 802.11ac Wave 2 |
MU-MIMO 2x2 160 MHz (contiguous 80 + 80 MHz) 2x2 80 + 80 MHz (discontiguous)
*2x2 160 MHz (contiguous 80 + 80 MHz) is not supported in Japan |
Wi-Fi Encryption |
WEP, WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPA2/WPA3-Personal, WPA3-Personal/Enterprise, OWE |
Button and Switch |
WPS, USB/SD eject, Power, Reset, Wi-Fi On/Off |
Size (Height x Width x Depth) |
77 mm x 280 mm x 169 mm
*The listed sizes of the RT1900ac and RT2600ac don’t include the antennas |
Weight |
0.7 kg |
Temperature |
Operating Temperature: 5°C to 40°C (40°F to 104°F) Storage Temperature: -20°C to 60°C (-5°F to 140°F) Relative Humidity: 5% to 95% RH |
Certification |
FCC UKCA CE BSMI VCCI RCM KC iDA TELEC JATE |
Wi-Fi Certification |
CE UKCA FCC NCC RCM iDA TELEC KC |
