Description
SPECIFICATIONS:
Network standards |
IEEE 802.3/IEEE 802.3u/IEEE 802.3ab/IEEE 802.3x/ IEEE 802.3af/IEEE 802.3at |
LED Indicator |
24 * Link/Act LEDs 2 * SFP LED 1 * PoE-MAX LED 1 * Power LED |
Interfaces |
24*10/100/1000 Base-T ports(Data/Power) |
Transmission media |
Recommended: CAT5/5e UTP or better |
Fan quantity |
2 |
Dimension |
440.0mmx284.0mmx44.0mm |
Level of protection |
Lightning protection for ports: 6kV Lightning protection for power: 6kV ESD: Air discharge: ±10kV Contact discharge: ±8kV |
Forwarding mode |
Store-and-forward |
Switch capacity |
48 Gbps |
Packet forwarding rate |
35.7Mpps |
Buffer |
2M |
MAC address table |
8K |
Jumbo frame |
N/A |
PoE budget |
Single port: AF: 15.4W, AT: 30W Whole device: 370W |
Power consumption |
/ |
Input voltage |
100-240V AC 50/60Hz |
Mounting |
Desktop mounting: support Wall mounting: support Rack mounting : support |
Environment |
Operating Temperature: 0℃~45℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Certification |
FCC、CE、RoHS |
