Description
SPECIFICATIONS:
HARDWARE |
|
4G Category |
LTE CAT.4 |
4G/3G standards |
FDD LTE,TDD-LTE,WCDMA |
Working Bands |
4G FDD LTE:B1/B3/B5/B7/B8/B20/B28AB 4G TDD-LTE:B38/B40/B41 3G WCDMA:B1/B5/B8 |
Max 4G speed |
DL:150Mbps; UL:50Mbps |
Wi-Fi standards |
802.11b/g/n |
Wi-Fi frequency |
2.4GHz |
Wi-Fi speed |
300Mbps |
Wi-Fi transmit Power |
Up to 20dBm |
Interface |
1 × 10/100 Mbps LAN/WAN Port 1 × 10/100 Mbps LAN Port 1 × Nano SIM Card Slot |
Button |
WPS/Reset |
Antennas |
2 External 4G/3G Antennas 2 Internal Wi-Fi Antennas |
LED indicators |
Internet Wi-Fi LAN 4G/3G Signal strength(3 Bars) |
Dimensions（L*W*H） |
127.4*90.5*26mm |
Weight |
About 134g |
Power supply |
Input power :AC 100V-240V 50/60Hz Output power:DC 9V==0.6A/5V==1A |
SOFTWARE |
|
WAN Type |
4G/3G or Wired |
4G/3G Features |
Auto-APN Auto dial-up Roaming SMS(Send/Receive/Delete) USSD Data limted PIN Management |
Wi-Fi functions |
Guest Wi-Fi Change Wi-Fi name&Wi-Fi key Wi-Fi schedule |
Wi-Fi security |
WEP,WPA-PSK, WPA2-PSK, WPA/WPA2 |
Software features |
APP/Local/remote management Parental control DHCP(DHCP Server and Client) Virtual Server(UPnP/DMZ/Port Forwarding) DDNS(DynDns, 88ip) VPN(PPTP Client/L2TP Client/PPTP Server) Firewall QOS Upgrade firmware from local or OTA IPV4/IPV6 |
CERTIFICATIONS |
|
Certifications |
CE Granted ROHS Granted |
WORKING ENVIRONMENT |
|
Temperature |
Operating Temperature: -5℃~45℃ Storage Temperature: -30ºC~70ºC |
Humidity |
Storage Humidity: 5% ~ 90% RH Non-condensing |
PACKAGE LISTS |
|
Package Contents |
1 * 4G LTE Router 1 * Ethernet cable 1 * Power adapter 1 * Quick Installation Guide |
