Description
SPECIFICATIONS:
HARDWARE |
|
4G Category |
LTE CAT.4 |
4G/3G standards |
TDD-LTE,TDD-LTE,WCDMAM |
Working band |
FDD-LTE: B1/B3/B5/B7/B8/B20/B28 TDD-LTE: B38/B40/B41 WCDMA: B1/B5/B8 |
Max 4G speed |
DL:150Mbps UL:50Mbps |
Wi-Fi standards |
802.11b/g/n/ac |
Wi-Fi frequency |
2.4GHz/5.8GHz |
Wi-Fi speed |
2.4GHz:300Mbps 5.8GHz:867Mbps |
Wi-Fi transmit Power |
2.4GHz:up to 20dBm 5.8GHz:up to 23dBm |
Interface |
1 × 10/100 Mbps LAN/WAN Port 1 × 10/100 Mbps LAN Port 1 × 2FF SIM Card Slot |
Button |
Power on/off WPS/Reset |
Antennas |
2 Detachable 4G/3G Antennas 2 Internal Wi-Fi Antennas |
LED indicators |
Power Wi-Fi LAN Internet 4G/3G Signal strength(3 Bars) |
Dimensions（L*W*H） |
185*126*60mm |
Weight |
About 350g |
Power supply |
Power adapter:Input power AC 100V-240V 50/60Hz Output power:DC 9V==1A |
SOFTWARE |
|
WAN Type |
4G/3G or Wired Support Failover |
Wi-Fi functions |
Wi-Fi name & Wi-Fi key Channel & Bandwidth Guest Network Wi-Fi schedule Wireless repeating Transmit power Beamforming+ WPS |
Wi-Fi security |
WPA-PSK, WPA2-PSK, WPA/WPA2 |
Software features |
APP/WEB DHCP Server VPN(PPTP Client/L2TP Client/PPTP Server) Firewall QOS Upgrade firmware from local or OTA IPV4/IPV6 |
CERTIFICATIONS |
|
Certifications |
CE ROHS |
WORKING ENVIRONMENT |
|
Temperature |
Operating Temperature : 0℃~40℃ Storage Temperature : -40℃ ~70℃ |
Humidity |
Operating Humidity : 10 %~90% RH non-condensing Storage Humidity : 5 %~ 90%RH non-condensing |
PACKAGE CONTENTS |
|
Package lists |
1 * 4G LTE Router 1 * Ethernet cable 1 * Power adapter 1 * Quick Installation Guide |
