Description
SPECIFICATIONS:
CAMERA |
|
Image Sensor |
1/3 Progressive Scan CMOS sensor |
Day and Night |
ICR type |
LENS |
|
Focal Length |
4 mm |
Aperture |
F1.6 |
FOV |
Horizontal FOV: 83°, Vertical FOV: 44°, Diagonal FOV: 98.6° |
ILLUMINATOR |
|
Supplementary Light |
2 IR Lights, 2 Spotlights |
Supplementary Light Distance |
Up to 30 m/100 ft (depending on environment) |
IR Wavelength |
850nm |
Night Vision Mode |
Smart Mode, Full Color Mode, Black & White Mode |
VIDEO |
|
Video Encoding Format |
H.265, H.264 |
Main Stream Resolution |
2560 ×1440, 2304 ×1296, 1920 × 1080, 1280 × 720 |
Sub Stream Resolution |
640 × 360, 352 × 288 |
Frame Rate |
1-30fps, Default 20fps |
Bit Rate |
512kbps -- 4096kbps |
Bit Rate Control |
CBR,VBR |
AUDIO |
|
Audio Encoding Format |
G.711A, G.711U, AAC |
Audio Sampling Rate |
8 kHz |
Audio Communication |
Two-way Audio, Voice Input |
IMAGE |
|
Image Enhancement |
DWDR, BLC, HLC, 3D DNR |
Privacy Mask |
4 Areas |
NETWORK |
|
Ethernet Port |
1 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet port |
ONVIF |
Support |
Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, ARP, WebSockets |
Web Browser |
Plug-in free live view: Chrome, Edge, Opera |
PAN&TILT |
|
Pan Movement Range |
0°--355° |
Tilt Movement Range |
0°--90° |
Preset |
6 |
Patrol |
Panoramic Patrol, Preset Patrol |
WI-FI |
|
Antenna |
Dual external antennas |
Wireless Standard |
IEEE 802.11 b/g/n |
Transmission Rate |
Up to 300 Mbps |
Channel Width |
20/40 MHz |
Modulation |
DSSS/OFDM |
Frequency Band |
2.4GHz: 2412MHz-2472MHz(CH1-CH13) |
Transmit Power |
2.4GHz: <0.092W(EIRP) |
Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
ALARM |
|
Smart Detection |
Motion Detection, Tempering Detection, Human Detection, Vehicle Detection |
Smart Linkage |
Sound&light Alert, Human Tracking |
DIY Audio |
3 Customized Audios |
INTERFACE |
|
Audio Input |
Built-in MIC |
Audio Output |
Built-in Speaker |
Storage |
Built-in Micro SD Card Slot, Up to 256 GB |
Reset Button |
Support |
LED Indicator |
Dual Color (red & blue) LED Indicator |
GENERAL |
|
Power |
12 V DC, 1A, Ø5.5mm&Ø2.1mm Power Plug |
Material |
Plastic |
Smart Integration |
Amazon Alexa |
Product Dimension |
138 mm x 120 mm x 187 mm (5.4 × 4.7 × 7.4) |
Package Dimension |
167 mm x 131 mm x 251 mm (6.6 × 5.2 × 9.9) |
Product Weight |
426g (0.94lb) |
With Package Weight |
840g (1.85lb) |
Protection Level |
IP65 |
Installation Method |
Wall Mounting, Ceiling Mounting, Pole Mounting |
Certification |
CE, RoHS, FCC, RCM, UKCA |
Temperature |
Operating Temperature: -30°C ~ 60°C (-22°F ~ 140°F) Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) |
Humidity |
Operating Humidity: 10% ~ 95% RH (non-condensing) Storage Humidity: 3% ~ 95% RH (non-condensing) |
Package Contents |
Camera Power Adapter (cord length: 3m) Installation Template Mounting Bracket Mounting Accessories Kit Waterproof Kit Quick Installation Guide |
