Description
SPECIFICATIONS:
HARDWARE |
|
Interface |
One 10/100/1000 Mbps Ethernet Port (PoE) |
Button |
1*Reset |
LED indicator |
1 x SYS |
Maximum Power Consumption |
11.5w |
Power Supply |
802.3af & 24V 0.5A Passive PoE |
Max. Number of Clients |
256 |
Recommended Clients |
38 |
Antenna |
2.4GHz: 2 x 4dBi 5GHz: 2 x 4dBi |
2.4GHz maximum power |
23+/-1.5dBm |
5GHz maximum power |
23+/-1.5dBm |
Reception Sensitivity |
802.11b -93 dBm 2.4 GHz 802.11n (MCS7) -73dBm 5 GHz 802.11a -93 dBm 5 GHz 802.11n (MCS7) -74 dBm |
WIRELESS |
|
Frequency Range |
2.4GHz&5GHz |
Standard&Protocol |
802.11a/b/g/n/ac(wave2) |
Maximum wireless speed |
2.4GHz: 300Mbps 5GHz: 867Mbps |
Bandwidth |
20MHz/40MHz/80MHz |
SOFTWARE |
|
Operating Mode |
AP/Client+AP |
Max. No. of SSID |
2.4GHz: 8 5GHz: 4 |
Hide SSID |
Supported |
OFDMA |
Supported |
Beamforming |
Supported |
Fast roaming (802.11k/v/r) |
Supported |
WEP |
Supported |
WPA-PSK |
Supported |
WPA2-PSK |
Supported |
WPA |
Supported |
WPA2 |
Supported |
Access control |
Supported |
Adjustable power transmit |
Supported |
Automatic channel |
Supported |
AP isolation |
Supported |
Guest network |
Supported |
Connected clients control |
Supported |
RSSI Threshold |
Supported |
Weak signal terminal elimination |
Supported |
Prioritize 5 GHz |
Supported |
VLAN tagging for SSID |
Supported |
LED control |
Supported |
MU-MIMO |
Supported |
Diagnostics tool |
Supported |
Reboot at specified interval |
Supported |
Scheduled reboot |
Supported |
Device management |
Web management Router management |
System logs |
Supported |
Firmware upgrade |
Supported |
Reboot |
Supported |
Reset |
Supported |
Backup configuration |
Supported |
Restore configuration |
Supported |
OTHERS |
|
Default IP |
192.168.0.254 |
Default username |
admin |
Default password |
admin |
Operation Temperature |
-30℃ ~ 50℃ |
Operating Humidity |
10%~90% non-condensing |
Storage Temperature |
-30℃ ~ 70℃ |
Storage Humidity |
10%~90% non-condensing |
