Description
SPECIFICATIONS:
HARDWARE |
|
Network standards |
IEEE 802.3、 IEEE 802.3u、IEEE 802.3x、IEEE 802.3af、IEEE 802.3at |
LED Indicator |
9 * Link/Ack LED indicators 1 * Power LED indicator |
Interfaces |
8*10/100 Base-TX Ethernet ports (Data/Power) 1*10/100 Base-TX Ethernet ports (Data) |
Transmission media |
Recommended: CAT5/5e UTP or better |
Dimension |
177.5mmx104.0mmx26.0mm |
Level of protection |
Lightning protection for ports: 6KV Lightning protection for power: 4KV ESD: Air discharge: ±10kV Contact discharge: ±8kV |
Forwarding mode |
Store-and-forward |
Switch capacity |
1.8 Gbit/s |
Packet forwarding rate |
1.34Mpps |
Buffer |
1.25Mb |
MAC address table |
4K |
PoE budget |
Single port: AF: 15.4W, AT: 30W Whole device: 58W |
Input voltage |
100－240V AC 50/60Hz 51V /1.25A DC（Power Adapter ） |
Mounting |
Desktop mounting: support Wall mounting: support Rack mounting:non-support |
Environment |
Operating Temperature: 0℃~45℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Certification |
FCC、CE、RoHS |
SOFTWARE |
|
Functions |
Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other. VLAN: ports 1 to 8 are isolated from each other, but can communicate with ports 9 (uplink port) respectively. |
